AVR-1802/882
Ref. No. Part No. Part Name Remarks Q’ty
OTHER PARTS GROUP
CN501 963 0085 506 9P connector socket (TUC-P) 1
CN502-504 963 0085 603 5P connector socket (TUC-P) 3
CN505 963 0085 700 6P connector socket (TUC-P) 1
CP506 963 0060 709 8P connector base 1
CP554 963 0060 903 15P connector base 1
 960 0184 000 Screw bracket 2
Ref. No. Part No. Part Name Remarks
DSP P.W.B. ASS'Y
SEMICONDUCTORS GROUP
IC801,802 269 0186 002 IC GP1FA502RZ
IC803 963 0073 903 IC 74VHCU04
IC805,806 963 0043 807 IC BA4510F
IC807 963 0073 709 IC M27W201-80B6
IC807S 963 0025 508 32P IC socket
IC808,809 963 0074 407 IC MM74LCX574WMX
IC810 960 0195 507 IC LC89055W
IC811 963 0074 805 IC RC1117S33ST
IC812 963 0079 208 IC CS49326-CL
IC813 963 0074 601 IC AK4527B-VQ
IC814~816 963 0024 004 IC NJM2068MD
IC817 269 0189 009 IC GP1FA502TZ
IC818,819 963 0074 203 IC MM74LCX244WMX
IC820 963 0074 708 IC RC1117S25T
IC822 960 0195 109 IC SN74LV00APW
IC828 963 0074 300 IC MM74HCT244WMX
IC829 960 0196 001 IC NJM7805FA (S)
IC830 963 0074 300 IC MM74HCT244WMX
IC831 960 0195 303 IC SN74LV4040APWR
IC832 963 0074 106 IC MM74HC151MX
Q804C 960 0196 603 Transistor KTC2874B
Q804FL,FR 960 0196 603 Transistor KTC2874B
Q804SL,SR 960 0196 603 Transistor KTC2874B
Q804SW 960 0196 603 Transistor KTC2874B
Q805 269 0083 901 Transistor DTA114EK
Q806 269 0082 902 Transistor DTC114EK
Q807 269 0083 901 Transistor DTA114EK
Q808 269 0082 902 Transistor DTC114EK
D801 960 0197 000 Diode KDS160
D806,807 960 0197 000 Diode KDS160
RESISTORS GROUP
R801 963 9004 342 Carbon chip 4.7 kohm 1/16W
R803 963 9004 342 Carbon chip 4.7 kohm 1/16W
R804,805 963 9003 385 Carbon chip 100 ohm 1/16W
R808 963 9004 274 Carbon chip 33 kohm 1/16W
R817~825 963 9004 070 Carbon chip 10 kohm 1/16W
R830 963 9004 342 Carbon chip 4.7 kohm 1/16W
R831 963 9004 070 Carbon chip 10 kohm 1/16W
R834,835 963 9004 342 Carbon chip 4.7 kohm 1/16W
R836 963 9004 070 Carbon chip 10 kohm 1/16W
R838 963 9004 070 Carbon chip 10 kohm 1/16W
R839 963 9004 342 Carbon chip 4.7 kohm 1/16W
R841 963 9004 339 Carbon chip 470 ohm 1/16W
R842 963 9004 342 Carbon chip 4.7 kohm 1/16W
R845R 963 9004 355 Carbon chip 47 kohm 1/16W
R848 963 9003 385 Carbon chip 100 ohm 1/16W
R850 963 9004 465 Carbon chip 75 ohm 1/16W
R854 963 9004 216 Carbon chip 2.2 kohm 1/16W
