Denon AVR-1905 User Manual

Before setting up the system
4
Press the SYSTEM SETUP button to enter the setting.
5
Press the ENTER or (down) button to switch to the Speaker Configuration set up.
*SYSTEM SET UP
NOTE:
Press the SYSTEM SETUP button again to finish system set up. System set up can be finished at any time. The changes to the settings made
up to that point are entered.
NOTE: Please make sure the “AUDIO” position of the slide switch
on the remote control unit.
3
ON / STANDBY
Turn on the power.
Press the Power ON/STANDBY switch (button).
(Main unit) (Remote control unit)
2
ON OFF
Press the Power switch (button) .
(Main unit)
• ¢ ON
The power turns on and indicator is light.
Set the power switch to this position to turn the power on and off from the included remote control unit.
• £ OFF
The power turns off and indicator is off.
In this position, the power cannot be turned on and off from the remote control unit.
1
Refer to “CONNECTIONS” (pages 7 to 15) and check that all connections are correct.
21
ENGLISH

Denon AVR-1905 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	80 W
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Digital Signal Processing (DSP)	Yes
HDMI in	0
Composite video in	4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	3
S-Video outputs quantity	2
Ethernet LAN	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	171 mm
Width	434 mm
Height	416 mm
Weight	11900 g
