Denon AVR-1905 User Manual

• After adjusting using the test tones, adjust the channel levels either according to the playback sources or to suit your tastes, as (described)
below.
1
Select the speaker whose level you want
to adjust.
The channel switches as shown below each time the button
is pressed.
2
Adjust the level of the selected
speaker.
FL C FR SR SBR SBL
SLSW
2
1
2
NOTE: Please make sure the “AUDIO” position of the slide
switch on the remote control unit.
Default setting of channel level is 0 dB.
The level of the selected speaker can be adjusted within
the range of +12 to –12 dB using the cursor buttons.
SW channel level can be turned off by decreasing one step
from –12 dB.
OFF ´ –12 dB ´ +12 dB
When the surround back speaker setting is set to
“1sp” for “Speaker Configuration”, this is set to “SB”.
“SB” appears only when “POWER AMP ASSIGN” setting
is SURR. BACK mode.
46
ENGLISH

Denon AVR-1905 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	80 W
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Digital Signal Processing (DSP)	Yes
HDMI in	0
Composite video in	4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	3
S-Video outputs quantity	2
Ethernet LAN	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	171 mm
Width	434 mm
Height	416 mm
Weight	11900 g
