Denon AVR-1905 User Manual

Dolby Pro Logic
II
x (Pro Logic
II
) mode
2
Select the Dolby Surround Pro Logic IIx mode.
LOGICII
Light
(Main unit) (Remote control unit)
3
Play a program source with the mark.
• For operating instructions, refer to the manuals of the respective components.
5, 74, 61 2
4
5, 7
1
9
5, 7
2
6
6
STANDARD
4
Select the surround parameter mode.
1
Select the function to which the component you want to play
is connected.
Example: DVD
FUNCTION
(Main unit) (Remote control unit)
Display
To perform this operation from the remote control unit, check that
the mode selector switch is set to “AUDIO”.
• The Dolby Pro Logic II indicator lights.
The Dolby Surround Pro Logic
IIx Cinema or Music mode can
be chosen directly by pressing
the CINEMA or MUSIC button
on the remote control unit
during playback in the Dolby
Surround Pro Logic IIx mode.
To play in the PL IIx mode, set “S. BackSp” at the Speaker Configuration setting to “1Sp” or “2Sp”.
To play in the PL IIx mode, set “Surround Back” at the Power Amp Assign setting.
SURROUND
PARAMETER
(Main unit)
(Remote control unit)
Display
47
ENGLISH

Denon AVR-1905 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	80 W
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Digital Signal Processing (DSP)	Yes
HDMI in	0
Composite video in	4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	3
S-Video outputs quantity	2
Ethernet LAN	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	171 mm
Width	434 mm
Height	416 mm
Weight	11900 g
