NOTE:
• When making parameter settings, the display will return to the regular condition several seconds after the last button was pressed and
the setting will be completed.
9
Press the ENTER button to finish surround parameter mode.
(Remote control unit)
6
Select the various parameters. (See “Surround parameters q” for a description of the various parameters.)
(Main unit) (Remote control unit)
7
Set the various surround parameters.
(Main unit) (Remote control unit)
8
When the surround parameters are set using the buttons on the main unit, stop operating buttons after completing the settings. The
settings are automatically finalized and the normal display reappears after several seconds.
(Remote control unit)
5
Select the optimum mode for the source.
(Main unit) (Remote control unit)
• When the “SB CH OUT” parameter is set to “ON”. (Set “S. BACK” at system set up to
“SMALL” or “LARGE”.)
(Pro Logic IIx
Cinema mode)
(Pro Logic IIx
Music mode)
(Pro Logic IIx
Game mode)
• When the “SB CH OUT” parameter is set to “OFF”. (Set “S. BACK” at system set up to
“NONE”.)
(Pro Logic II
Cinema mode)
(Pro Logic
II
Music mode)
(Pro Logic
II
Game mode)
(Dolby Pro Logic
mode)
48
ENGLISH
