Denon AVR-1908 - Page 159

159
AVR-1908 / AVR-788
AVR-1908 E2/E2A model
CPU P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC801 00D 960 0100 301 IC KIA7812API J126781200040S
IC802 00D 963 0326 906 IC LC72722PM J124727220010S
IC803 963243000010D IC CPU MICRO PROCESS
M30879FLBFP 8952190800012
IC804 00D 262 2813 903 IC SN74AHCTO8-EL2 J040740800190S
IC805 00D 963 0244 907 IC SN74LV14APWR J040741400180S
IC806 00D 963 0367 307 IC SN74AHCU04PWR J040740400290S
IC807 00D 963 0367 204 IC SN74HC151PWR J040741510070S
Q801 00D 963 0120 704 TR KRA102S J520010200210S
Q806 00D 963 0121 509 TR KTC3875S J522038750210S
Q807 00D 960 0285 006 TR KRC104S J522104S00210S
Q808 00D 963 0148 508 TR KTA1504S J520015040150S
Q809-812 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q813 00D 963 0121 606 TR KRC107S J522107S00210S
D801 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D802-808 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D809-811 00D 963 0341 305 D,ESD IMSA-6802-01A K067680200010S
D812 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D813,814 00D 963 0245 100 D,SWITCHING KDS226ST1(C3) K005022600020S
ZD801 00D 963 0047 502 D,ZENER MTZJ3.3B K06003R344520S
RESISTORS GROUP
R822 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
CAPACITORS
GROUP
C801 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C805 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C806 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C808,809 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C810 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C811 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C812 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C813-818 nsp C,CERAMIC 100PF-J/50V D010101167160S
C819,820 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C821 nsp C,CERAMIC 560PF-J/50V D010561167160S
C822 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C823 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C824,825 nsp C,CERAMIC 27PF-J/50V D010270167160S
C826 nsp C,CERAMIC 330PF-J/50V D010331167160S
C827 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C828 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C829,830 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C831 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C833 nsp C,CERAMIC 100PF-J/50V D010101167160S
C834 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C835 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C836 nsp C,CERAMIC 100PF-J/50V D010101167160S
C837 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C838 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
d
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
WhenupdateFirmware,please
confirmalastversioninSDI.
Usetheserviceboardafter
updatingit.
