Denon AVR-1908 Service Manual

22
AVR-1908 / AVR-788
2.3. MONITOR OUT (S) Output NG
MONITOR OUT (S) Output NG
※ When checking operation, select
DVD for the function.
(COMPONENT1 Input)
Checking the video convert ON/OFF settings
Video convert ON Video convert OFF
Input
CVBS
Input
S
I n pu t
COMPONENT
I n pu t
CVBS
Input
S
Input
COMPONENT
D E No output No output E No output
2.3. MONITOROUT(S)出力 NG
MONITOROUT(S)出力 NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
(COMPONENT1入力 )
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON/OFFの設定確認
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄOFF
入力
CVBS
入力
S
入力
COMPONENT
入力
CVBS
入力
S
入力
COMPONENT
D へ E へ 出力されません 出力されません E へ 出力されません

Denon AVR-1908 Specifications

General

Channels	7.1
Power Output	90W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Type	AV Receiver
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	2 Optical, 2 Coaxial
Tuner	AM/FM
Frequency Response	10Hz-100kHz (+1, -3dB)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB
Power Consumption	460W
Surround Sound Formats	Dolby Digital, DTS
Total Harmonic Distortion	0.08%
Tuner Frequency Range	AM: 522-1611 kHz, FM: 87.5-108.0 MHz
Standby Power Consumption	Less than 1W
