229
AVR-1908 / AVR-788
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model
788E3 : U.S.A. & Canada model (AVR-788)
BKE2 : Europe model(
Black model) SRE2 : Europe model(Silver model)
E2A : Asia model (Premium Silver model)
EUT : Taiwan R.O.C. model (
Premium Silver model)
E1C : China model (
Premium Silver model)
Ref. No. Part No. Part Name Remarks
Q't
y
Ne
w
11A nsp FRONT P.W.B. ASSY E3 7025HK0706011 1 *
11A nsp FRONT P.W.B. ASSY 788E3 7025HK0706071 1 *
11A nsp FRONT P.W.B. ASSY E2 7025HK0706021 1 *
11A nsp FRONT P.W.B. ASSY E2A 7025HK0706041 1 *
11A nsp FRONT P.W.B. ASSY EUT 7025HK0706051 1 *
11A nsp FRONT P.W.B. ASSY E1C 7025HK0706061 1 *
9 POWER SW P.W.B. 7028065877010
10 FUNC P.W.B. 7028065874010
11 FRONT P.W.B. 7028065871010
14 HEAD PHONE P.W.B. 7028065876010
21 V- AUX P.W.B. 7028065872010
22 MIC P.W.B. 7028065873010
55 SPEAKER P.W.B. 7028065875030
33A nsp 2CH P.W.B. ASSY E3 7025HK0706014 1 *
33A nsp 2CH P.W.B. ASSY 788E3 7025HK0706074 1 *
33A nsp 2CH P.W.B. ASSY E2 7025HK0706024 1 *
33A nsp 2CH P.W.B. ASSY E2A 7025HK0706044 1 *
33A nsp 2CH P.W.B. ASSY EUT 7025HK0706054 1 *
33A nsp 2CH P.W.B. ASSY E1C 7025HK0706064 1 *
33 2CH P.W.B. 7028065901010
50A nsp MAIN P.W.B. ASSY E3 7025HK0706010 1 *
50A nsp MAIN P.W.B. ASSY 788E3 7025HK0706070 1 *
50A nsp MAIN P.W.B. ASSY E2 7025HK0706020 1 *
50A nsp MAIN P.W.B. ASSY E2A 7025HK0706040 1 *
50A nsp MAIN P.W.B. ASSY EUT 7025HK0706050 1 *
50A nsp MAIN P.W.B. ASSY E1C 7025HK0706060 1 *
50 MAIN P.W.B. 7028065861010
51A nsp CPU P.W.B. ASSY E3 7025HK0706015 1 *
51A nsp CPU P.W.B. ASSY 788E3 7025HK0706075 1 *
51A nsp CPU P.W.B. ASSY E2 7025HK0706025 1 *
51A nsp CPU P.W.B. ASSY E2A 7025HK0706045 1 *
51A nsp CPU P.W.B. ASSY EUT 7025HK0706055 1 *
51A nsp CPU P.W.B. ASSY E1C 7025HK0706065 1 *
51 CPU P.W.B. 7028065911010
