AVR-1908 / AVR-788
z 46 00D 963 0381 200 TRANS MAIN E2/E2A 8200960660310S 1 *
z 46 00D 963 0381 307 TRANS MAIN E1C 8200960660320S 1 *
70 963406000070D CHASSIS BACK E3 3207212156001S 1
*
70 963406000080D CHASSIS BACK 788E3 3207212156011S 1 *
70 00D 963 0381 608 CHASSIS BACK E2/E2A 3207212156100S 1 *
70 00D 963 0381 705 CHASSIS BACK EUT 3207212156200S 1 *
70 00D 963 0381 802 CHASSIS BACK E1C 3207212156300S 1 *
71 00D 963 0145 608 TUNER PACK E3/788E3 E903014000020S 1
71 00D 963 0145 705 TUNER PACK E2/E2A/EUT/E1C E903014100030S 1
72 nsp STOPPER AC CORD 4380210002000S 1
z 73 00D 963 0292 205 AC CORD E3/788E3 L068125100020S 1
z 73 00D 963 0292 409 AC CORD E2/E2A L068250250040S 1
z 73 00D 963 0292 302 AC CORD EUT L068125110000S 1
z 73 00D 963 0352 404 AC CORD E1C L068250060010S 1
80 00D 963 0361 302 CABINET TOP E3/788E3/BKE2 3000210936000S 1
80 00D 963 0381 909 CABINET TOP
SRE2/E2A/EUT/E1C
3000210926000S 1 *
81 nsp COVER SAFETY except E3 model 4310212122010S 1
82 nsp COVER HOLDER except E3 model 4310213701000S 1
83 nsp CUSHION SIDE 4050211095000S 3 *
84 nsp CUSHION PCB 4050211105000S 1 *
85 nsp
SUPPORTER BUTTON LOCK
4070000020000S 1 *
86 nsp LABEL ORIGIN EUT/E1C 5507003020021S 1
87 nsp CLAMP(MTG) 4330000310000S 3
88 00D 513 3333 005 LABEL (TRANS) 5507051740120S 1
89 nsp SHEET CABINET 788E3 1210210235000S 4 *
90 00D 342 0043 000 FERRITE CLAMP102010N 1
★
nsp
LABEL RATING FUSE CAUTION
5527042410030S 1
T1 00D 996 0018 706 TR PNP 2SB1560-Y J5011560Y0000S 5
T2 00D 963 0280 107 TR NPN 2SC3964 J502396400000S 5
T3 00D 996 0018 706 TR NPN 2SD2390-Y J5032390Y0000S 5
Wires
★
00D 963 0382 005
CABLE,FLAT CARD 1.0*18*100
CP1007A_CP1007B N711181033810S 1
★
00D 963 0365 806
CABLE,FLAT CARD 1.25*15*130
TUNER_CP808 N712151344810S 1
★
00D 963 0365 909
CABLE,FLAT CARD 1.25*35*150
CP301A_CP301B N712351534810S 1
Screws
Ansp
SCREW(3X8 B-TYPE ZNW/BH)
E3/788E3 B020030081B10S 65
Ansp
SCREW(3X8 B-TYPE ZNW/BH)
E2/E2A/EUT/E1C 70
Bnsp
SCREW(3X8 BK WASHER PI12)
E3/788E3 1500001456020S 5
Bnsp
SCREW(3X8 BK WASHER NI12)
E2/E2A/EUT/E1C 1500001456030S 4
Cnsp
SCREW(3X15 B-TYPE ZNW/BH)
B020030151B10S 2
Dnsp
SCREW(3X10 B-TYPE(DOT) BK/BH)
E3/788E3 B020030103B11S 36
Dnsp
SCREW(3X10 B-TYPE(DOT) BK/BH)
E2/E2A/EUT/E1C B020030103B11S 41
Ensp
SCREW(3X14 P+S-WASHER ZNY/HH)
B018230141H11S 25
Fnsp
SCREW(3X17 B-TYPE ZNW/BH)
B020030171B10S 3
G 00D 963 0048 307
SCREW(4X8 B-TYPE(DOT) BK/BH)
E3/788E3/BKE2 1500040083B10S 6
G 00D 963 9004 012
SCREW(4X8 B-TYPE(DOT) NI/BH)
SRE2/E2A/EUT/E1C
1500040084B10S 6
Hnsp
SCREW(4X10 P+S-WASHER ZNW/BH)
B028940101B10S 4
Ref. No. Part No. Part Name Remarks
Q't
y
Ne
w
d
d
To Next Page
