Denon AVR-1908 Service Manual

7
AVR-1908 / AVR-788
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
下記フロー図の矢印の順番にはずしてください。
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
再組み立ての場合は、下記のフローの逆の順番に組立ててください
• In the case of the re-assembling, observe "attention of assembling" it.
再組み立ての場合は、「組立のご注意」を遵守してください。
CABINET TOP
PANEL FRONT ASSY CHASSIS BACK ASSY TRANS
Refer to "DISASSEMBLY 1.PANEL FRONT ASSY" Refer to "DISASSEMBLY 2.CHASSIS BACK ASSY" Refer to "DISASSEMBLY 6.TRANS"
and "EXPLODED VIEW" and "EXPLODED VIEW" and "EXPLODED VIEW"
9 : POWER SW ASSY 55 : SPEAKER ASSY
10 : FUNCTION ASSY 71 : TUNER PACK
11 : FRONT ASSY
14 : HEAD PHONE ASSY
CPU ASSY
21 : V. AUX ASSY Refer to "DISASSEMBLY 3.HDMI PWB ASSY"
22 : MIC ASSY and "DISASSEMBLY 4.CPU ASSY"
and "EXPLODED VIEW"
51 : CPU PWB ASSY
52 : INPUT PWB ASSY
53 : VIDEO PWB ASSY
54 : HDMI PWB ASSY
CHASSIS MAIN ASSY
Refer to "DISASSEMBLY 5.CHASSIS MAIN ASSY"
and "EXPLODED VIEW"
33 : 2CH PWB ASSY
50 : MAIN PWB ASSY
56 : POWER SUPPLY PWB ASSY
57 : POWER PWB ASSY

Denon AVR-1908 Specifications

General

Channels	7.1
Power Output	90W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
Type	AV Receiver
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	2 Optical, 2 Coaxial
Tuner	AM/FM
Frequency Response	10Hz-100kHz (+1, -3dB)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB
Power Consumption	460W
Surround Sound Formats	Dolby Digital, DTS
Total Harmonic Distortion	0.08%
Tuner Frequency Range	AM: 522-1611 kHz, FM: 87.5-108.0 MHz
Standby Power Consumption	Less than 1W
