Denon AVR-1911 Service Manual

100
Pin Pin Name Synbol I/O Type Pullup
Lv
Cnv
STBY Stop Function
125 P155/(RXD6) SUB UPDATE O C - - O/L O/L
SUB UPDATE mode control (DPMS/DENON WRITTER).
Normal:L. SUB rewriting mode:H(SUB reset)
126 P154/(TXD6) iPod DET I - SW3VPu - O/L O/L
MINI JACK connection detection pin for DOCK connection
(Connection:H)
127 P153 USB PDN(19)/NC(16) O C NET3VPu - O/L O/L USB(TELECHIPS) control pin
128 P152/RXD7 NC I - Pd - - - NC
129 P151/CLK7 NC I - Pd - - - NC
130 VSS VSS - - - - - - GND
131 P150/TXD7 NC I - Pd - - - NC
132 VCC VCC - - - - - - +3V
133 P107/(AN7)/(KI3) NC O C - - O/L O/L NC
134 P106/AN6/KI2 KEY3 I - M3VPu - I I Button input 3
135 P105/AN5/KI1 KEY2 I - M3VPu - I I Button input 2
136 P104/AN4/KI0 KEY1 I - M3VPu - I I Button input 1
137 P103/(AN3) NC I - Pd - - - NC
138 P102/(AN2) NC I - Pd - - - NC
139 P101/AN1 MODEL I - M3VPu/Pd - I I MODEL switch input
140 AVSS AVSS - - - - - - Analog GND
141 P100/AN0 MODE I - M3VPu/Pd - I I Destination switch input
142 VREF VREF - - - - - - Standard power input +3V
143 AVCC AVCC - - - - - - Analog power +3V
144 P97/(RXD4) RED LED O C - - O/H O/L POWER/STANDBY LED control pin (ON:H)

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
