Denon AVR-1911 Service Manual

143
PCB HDMI ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
U1001 nsp IC ADV7840 J040784005510S
U1301 00D9630244907 IC SN74LV14APWR J040741400180S
U1302 nsp IC ABT1030 J080103005510S
U1303 nsp
IC MEMORY-RAM
(IS42S16400F-6TL)
J001421640060S
U1501 963239010410S IC ADV7511BSTZ-225 J040751100010S *
U1703 00D2623077900 IC TC74VHCU04FT J040740405580S
U1706 236810062608S IC LC89058W-E J046890580020S
U1707 963243010640S
IC PAL/PLD
(EPM3032A-TC44)
8952161100040 *
U1901 nsp IC ADSP21367KSWZ2A1181 J080213675520S
U1902 963239010680S IC W9864G2IH-6 J001986460060S *
U1903 963243010650S
IC MEMORY FLASH
(EN29LV160BB-70TIP)
8952161100030
U2101 236810086505S IC AK5358BET-E2 J043535805520S *
U2102 236810073509S IC AK4358VQ-L J042435800010S
U2103-2106 963239001880S IC AZ4580M J121458000020S
U2301 963243010660S
IC MEMORY FLASH
(EN29LV160BT-70TIP)
8952161100050 *
U2302 963239010380S IS42S16400F-6TL J001421640060S
U2303 nsp IC MFI341S2164 J044341216410S
U2304 963239008830S IC TCC8600 32BIT J085860000010S
U2305 236810070500S IC AK4424ET-E2 TSSOP16 J042442405520S
U2306 00D2790055907 SW,POLY MICROSMD175F G300017500010S
U2501-2503 nsp IC EX3AV J048030030010S *
U2504,2505 nsp IC PQ033DNA1ZPH J126033010010S
U2506 234810015507S IC BU4248F J126424800010S
U2901 00MHC007805KZ IC TC74VHCT125AFT J040741255580S
U2902 234810014504S IC MC14094BDTR2G J040140940020S
U2903 00D2623437906 IC TC74VHCT244AFT J040742445540S
U2904 00D2623410907 IC TC74VHCT08AFT J040740800090S
U2905 00D2623444902 IC TC74VHC08FT J040740800280S
U3102
963243010620S
IC CPU MICRO PROCESS
( R5F64169DFD)
8952161100010
U3103 246810026500S IC R1EX24256ASAS0A J000242565550S
U3301 963243010630S
IC CPU MICRO PROCESS
(R5F3650KNFB)
8952191100010 *
Q1001 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1002 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1003 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1004 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1005 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1006 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1007 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1008,1009 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1301 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1302 00D2750110905 SEMI HN1K02FU J543102000020S
Q1501 00D9630120704 TR KRA102S(PB) J520010200210S
Q1502 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1901 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1902 00D9630120704 TR KRA102S(PB) J520010200210S
NOTE :
When update Firmware,
please conrm a last
version in SDI.
Use the service board
after updating it.

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
