Denon AVR-1911 Service Manual

56
＋
LINE IN
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN/EXT IN
0dBFS
2.0Vrms
PREOUT
159mVrms
-2.0dB
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
-20dBFS(DIG.IN)
AK4424ET
200mV
MAX SIGNAL LEVEL 2.00Vrms
＋
SPEAKER
OUT
PREOUT
MUTE
+30dB
SP OUT
4.48Vrms
/
8Ω
MONO
HPF
D/A
from
DA SB-ch
TO
MAIN
SB-ch
FRONT/ZONE ASIGN 0dB
MONO
HPF
MONO
TONE
D/A
PREOUT
MUTE
ZONE3 NJW1194
ZONE2 NJW1194
from
F-ch
TONE
from
EXT.IN SB-ch
MONO
AVR3311 ONLY
AVR2311/3311,
ONLY
R2A15220FP
LEVEL DIAGRAM
ZONE2/3
+2
9d
B

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
