74
Inputting characters
10 Key input screen
nDisplay of a 10 Key input screen
Default
TUNER
CD
BD
DVD
TV
SAT/CBL
TUNER
CD
BD
DVD
TV
SAT/CBL
Rename
[1/2]
Input
[CH+] Insert [CH-] Delete
[ 0-9]
[SEARCH] Keyboard
[RETURN][ENTER] Enter Cancel
q
w
q Character input section
w Guide for operation buttons
Using the number buttons
1
Display the screen for inputting
characters
(vpage 70
“Menu map”).
2
Press SEARCH while a keyboard
screen is displayed.
A 10 Key input screen is displayed.
•When a button from
0 – 9 is pressed while
the soft keyboard screen is being displayed,
the screen switches to the 10 Key input
screen.
3
Place the cursor at the character to be changed with
o p and press the number button (0 9) until the
desired character is displayed.
•The types of characters that can be input are as shown below.
1 . @ - _ / : ˜ M N O m n o 6
A B C a b c 2 P Q R S p q r s 7
D E F d e f 3 T U V t u v 8
G H I g h i 4 W X Y Z w x y z 9
J K L j k l 5
0 (Space) ! “ # $ % & ‘ ( )
z
+ ,
; < = > ? [ \ ] ^ ` { | }
•When you press
SHIFT while you type in, you can change
uppercase characters to lowercase and vice versa.
•For entering the characters assigned to one number button
continuously, press p to move the cursor to the right after entering
a character then enter the next character.
•For entering characters assigned to separate buttons, press the
number button continuously. The cursor automatically moves to
the next position, and the entered character is registered.
4
Repeat step 3 to change the name then press ENTER
to register it.
Example: For changing the input source from “DVD” to “DENON”
q Place the cursor at “V”.
DVD
w Press
twice.
DED
“V” changes to “E”.
e Press
twice.
DEN
“E” is automatically registered, and “D” changes
to “N”.
r Press p.
DEN
“N” is registered.
t Press
three times.
DENO
Input “O”.
y Press p.
DENO
“O” is registered.
u Press
twice.
DENON
Input “N”.
i Press
ENTER to register the input source name.
Using the cursor buttons
1
Display the screen for inputting characters
(vpage 70 “Menu map”).
2
Press SEARCH while a keyboard screen is displayed.
A 10 Key screen is displayed.
3
Use o p to set the cursor to the character you want
to change.
4
Use ui to change the character,
then press ENTER.
•The types of characters that can be input
are as shown below.
GUpper case charactersH
ABCDEFGHIJKLMNOPQRSTUVWXYZ
GLower case charactersH
abcdefghijklmnopqrstuvwxyz
GSymbolsH ! “ # $ % & ‘ ( )
z
+ , - . / : ; <
= > ? @ [ \ ] ^ _ ` { | } ˜
GNumbersH
0123456789 (Space)
•When you press
SHIFT while you type in, you can change
uppercase characters to lowercase and vice versa.
5
Repeat steps 3 and 4 to change the name then press
ENTER to register it.
Basic version
Advanced version
Information
Advanced version

Table of Contents

Other manuals for Denon AVR-1912

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-1912 and is the answer not in the manual?

Denon AVR-1912 Specifications

General IconGeneral
Impedance47 Ω
Receiver typeSurround
Frequency range10 - 100000 Hz
Input sensitivity200 mV
Audio output channels7.1 channels
Audio A/D Converter (ADC)24-bit/96kHz
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.08 %
Power output per channel (1KHz@6 Ohm)125 W
Power output per channel (20-20KHz@8 Ohm)90 W
HDMI in6
Composite video in3
Component video (YPbPr/YCbCr) in1
Headphone connectivity6.3 mm
Connectivity technologyWired
Speakers connectivity typeBanana connector/Binding posts
Audio formats supportedAAC, FLAC, MP3, WAV, WMA
Image formats supportedJPG
Wi-FiNo
Ethernet LANYes
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Preset stations quantity56
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL
Display-
Product colorBlack
Audio decodersDolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibilityiPhone, iPod
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)460 W
Weight and Dimensions IconWeight and Dimensions
Depth382 mm
Width435 mm
Height167 mm
Weight10200 g
