Denon AVR-1912 User Manual

91
System Setup
ZONE2 Setup Default settings are underlined.
Set the audio to play back with multi-zone (ZONE2).
“ZONE2 Setup” is displayed when “ZONE2” is selected with “Amp Assign”.
Setting items Setting details
Lch Level
Adjust the left channel
output level.
–12dB – +12dB (0dB)
Rch Level
Adjust the right channel
output level.
–12dB – +12dB (0dB)
Volume Limit
Make a setting for
maximum volume.
OFF : Do not set a maximum volume.
–20dB (61) / –10dB (71) / 0dB (81)
This is displayed from 0 to 99 when “Volume Display” (vpage92)
is set to “Absolute”.
Power On Level
Define the volume setting
that is active when the
power is turned on.
Last : Use the memorized setting from the last session.
– – – (0) : Always mute when power is turned on.
–80dB – 18dB (1 – 99) : The volume is adjusted to the set level.
This is displayed from 0 to 99 when “Volume Display” (vpage92)
is set to “Absolute”.
Mute Level
Set the amount of
attenuation when muting
is on.
Full : The sound is muted entirely.
–40dB : The sound is attenuated by 40 dB down.
–20dB : The sound is attenuated by 20 dB down.
Setting items Setting details
Other
(Continued)
Notification : Sets the display of a notification message when the latest
firmware is released.
Update : Displays a notification message on this unit’s menu screen when
the latest firmware is released with “Firmware Update”. The notification
message is displayed for about 20 seconds when the power is turned on.
Connect to broadband Internet (vpage12) when using this function.
•ON : Display update message.
•OFF : Do not display update message.
•When you press ENTER during display of the
notification message, the “Check for Update”
screen is displayed (Refer to page93 for more
information on “Firmware Update”).
•Press RETURN B to erase the notification
message.
Upgrade : Display a notification message on this unit’s menu screen
when downloadable firmware is released with “Add New Feature”. The
notification message is displayed for about 20 seconds when the power
is turned on. Connect to broadband Internet (vpage 12) when using
this function.
•ON : Display upgrade message.
•OFF : Do not display upgrade message.
•When you press ENTER during display of the notification message, the
“Add New Feature” screen is displayed (Refer to page 93 for more
information on “Add New Feature”).
•Press RETURN B to erase the notification message.
Rhapsody Account
Set or change Username
and Password
(vpage40 “Listening to
Rhapsody”).
Username / Password / Clear
•For character input, see page73.
Napster Account
Set or change Username
and Password
(vpage35 “Listening to
Napster”).
Username / Password / Clear
•For character input, see page73.
Network Info.
Display network information.
Friendly Name / DHCP=ON or OFF / IP Address / MAC Address
Basic version
Advanced version
Information
Advanced version
BD

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
