Page #90 background imageLoading...
Page #90 background image
87
System Setup
Audio Setup
Default settings are underlined.
Make settings for audio playback.
Setting items Setting details
2ch Direct/Stereo
Select the method for
setting the speakers used
in the 2-channel direct and
stereo playback modes.
Setting : Select the method for setting the speakers used in the 2-channel
direct and stereo playback modes.
•Basic : The settings at “Speaker Setup” (vpage83) are applied.
•Custom : Make separate settings for 2-channel. Make the following
settings:
Front : Set the front speaker size.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
If “Speaker Config.” – “Subwoofer” (vpage 83) is set to “No”,
the setting is automatically set to “Large”.
SW : Set the presence of a subwoofer.
•Yes : Use a subwoofer.
•No : Select when a subwoofer is not connected.
If “Speaker Config.” – “Subwoofer” (vpage 83) is set to “No”,
the setting is automatically set to “No”. If the “Front” setting is
“Small”, the setting is automatically “Yes”.
SW Mode : Select low range signals to be reproduced by subwoofer.
•LFE : When the “2ch Direct/Stereo” – “Front” setting is set to “Large”,
the LFE signal alone is output from the subwoofer. Also, when the “2ch
Direct/Stereo” – “Front” setting is set to “Small”, the front channel low
range signal is added to the LFE signal output from the subwoofer.
•LFE+Main : The front channel low range signal is added to the LFE signal
output from the subwoofer.
This setting can be set made “2ch Direct/Stereo” – “SW” is set to
“Yes”.
Crossover : Set the maximum frequency of the bass signal output from
each channel to the subwoofer.
•40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /
250Hz
•This setting can be set made “2ch Direct/Stereo” – “SW” is set to
“Yes”.
•If the “2ch Direct/Stereo” – “Front” setting is “Large” and the “SW
Mode” setting is “LFE”, “Full Band” is displayed and the setting cannot
be made.
Setting items Setting details
2ch Direct/Stereo
(Continued)
Distance FL / Distance FR : Select the speaker.
•0.0ft – 60.0ft (12.0ft) / 0.00m – 18.00m (3.60m) : Set the distance to
the speaker.
Set the difference in the distance between the speakers to less than
20.0 ft (6.00 m).
Level FL / Level FR : Select the speaker.
•–12.0dB – +12.0dB (0.0dB) : Adjust the level of each channel.
Auto Surround
Make setting for
memorizing surround mode
setting for each input signal
type.
ON : Memorize settings. Automatically play with the last used surround
mode.
OFF : Do not memorize settings. Surround mode does not change
according to input signal.
•The auto surround mode function lets you store in the memory the
surround mode last used for playing the four types of input signals listed
below.
q Analog and PCM 2-channel signals
w Dolby Digital and DTS 2-channel signals
e Dolby Digital and DTS multi-channel signals
r LPCM Multi-channel signals
•When playing in PURE DIRECT, the surround mode does not change
even if the input signal is changed.
EQ Customize
Set the equalizers that
will not be used to not
be displayed when the
“MultEQ
®
” equalizer is
selected.
The equalizer mode in which
“Not Used” is selected
cannot be stored and
recalled in the Quick Select
function.
Audyssey Byp. L/R : Set when not using “Audyssey Byp. L/R” equalizer.
•Used : Use.
•Not Used : Do not use.
Set so that “Audyssey Byp. L/R” settings can be made when
Audyssey
®
Auto Setup is performed.
Audyssey Flat : Set when not using “Audyssey Flat” equalizer.
•Used : Use.
•Not Used : Do not use.
Set so that “Audyssey Flat” settings can be made when Audyssey
®
Auto Setup is performed.
Manual : Set when not using the “Manual” equalizer.
•Used : Use.
•Not Used : Do not use.
Basic version
Advanced version
Information
Advanced version
BD

Table of Contents
