Denon AVR-1912E3 User Manual

137
Ref. No. Part No. Part Name Remarks Q'ty New
27 nsp BRACKET SIDE 4010210686000S 1
28 nsp CHASSIS BACK 1912BKE3 3207213806100S 1 *
28 nsp CHASSIS BACK 2112CIBKE3 3207213806000S 1 *
28 nsp CHASSIS BACK 1912BKE2,1912BKEA 3207213806200S 1 *
28 nsp CHASSIS BACK 1912SPE1C 3207213806300S 1 *
29 nsp STOPPER CORD AC E3,E1C 4380210002000S 1
z
30 00D9630292205 CORD ASSY E3 L068125100020S 1
z
30 963611500410S CORD ASSY E1C L068250060011S 1 *
z
31 963101100020S POWER TRANS MAIN E3 8200960611030S 1 *
z
31 963101101010S POWER TRANS MAIN E2,EA 8200960610770S 1 *
z
31 963101101020S POWER TRANS MAIN E1C 8200960610780S 1 *
32 nsp BRACKET H SINK 4010056906010S 5
33 nsp HEAT SINK MAIN 2120211988000S 1
★
34 00D9960018706 TR 2SB1560-Y
Q410,Q422,Q434,Q446,
Q458,Q470,Q482
J5011560Y0000S 7
★
35 00D9960018706 TR 2SD2390-Y
Q404,Q416,Q428,Q440,
Q452,Q464,Q476
J5032390Y0000S 7
★
36 00D9630280107 TR 2SC3964
Q409,Q421,Q433,Q445,
Q457,Q469,Q481
J502396400000S 7
41 nsp SPACER CARD 4300210062000S 1
42 nsp BRACKET SMPS 4010214886000S 1
43 963403100020S CABINET TOP BK 3007211916000S 1 *
43 963403100480S CABINET TOP SP 3007211916010S 1 *
44 nsp BRACKET HDMI 4010215226000S 1 *
45 nsp SUPPORTER PCB 4070211653000S 1
★
50 963606010490S CABLE,FLAT CARD 1.0MM N711402912480S 1
★
51 nsp CLAMP CABLE 4330040343010S 8
★
52 nsp CLAMP WIRE(MTG) 4330000310000S 1
SCREWS
A nsp
SCREW
+2S 3X8 B-TYPE(DA CHENG) ZNW/BH
1912BKE3 B020030081B10D 23
A nsp
SCREW
+2S 3X8 B-TYPE(DA CHENG) ZNW/BH
2112CIBKE3,1912BKE2,
1912BKEA,1912SPE1C
B020030081B10D 20
B nsp
SCREW
+2S 3X15 B-TYPE ZNW/BH
B020030151B10S 2
C nsp
SCREW
+2S 3X8(ROUND)(DA CHENG) BK/BH
1912BKE3 B020230083B10D 49
C nsp
SCREW
+2S 3X8(ROUND)(DA CHENG) BK/BH
2112CIBKE3,1912BKE2,
1912BKEA,1912SPE1C
B020230083B10D 50
D nsp SCREW +2S 3X8 ZnY WASHER PI12 1500001456010S 1
E nsp SCREW +2S 3X8 PI9.5 B-TYPE ZNW 1500001206010S 2
G nsp
SCREW
+3S 4X10 P+S-WASHER(ROUND)BK/BH
B028940101B11S 4
H nsp
SCREW
+2S 3X14 P(Φ6)+S-WASHER ZNY/HH
B018230141H11S 21
I nsp
SCREW
+2S 3X17 B-TYPE(DA CHENG) BK/BH
B020030171B10D 3
J nsp
SCREW
+2S 4X8 B-TYPE(DOT)(DACHENG) BK/BH
2112CIBKE3,1912BKE3 1500040083B10D 6
J nsp
SCREW
+2S 4X8 B-TYPE(DOT)(DACHENG) BK/BH
1912BKE2,1912BKEA 1500040083B10D 8
J nsp
SCREW
+2S 4X8 B-TYPE(DOT)(DACHENG) NI/BH
1912SPE1C 1500040084B10S 6
K nsp
SCREW
+2S 3X10 B-TYPE(DOT)(DA CHENG) BK/BH
B020030103B11D 25
L nsp SCREW +3S 3X6(DOT)CBTS(S)-B B020930063B10S 10
