Denon AVR-1912E3 User Manual

179
Ref. No. Part No. Part Name Remarks Q'ty New
z
F100 963652010510S FUSE T2A/250V 2112CIE3,1912E3 N751502001160S
z
F100 963652010500S FUSE T1.6A/250V
1912E2,1912EA,
1912E1C
N751501601160S
z
F101 963652010520S FUSE T6.3A/250V 2112CIE3,1912E3 N751506301160S
z
F101 963652010910S FUSE T3.15A/250V
1912E2,1912EA,
1912E1C
N751503151160S
JACK1 963643010360S TER, BOARD 6P JB-602A-02 G613602A0200YS
JACK2 963646001690S TER, BOARD 8P MST-108V1 G614108V1010MS
JK100 963641011240S SOCKET,POWER AC 1912E2,1912EA G4300152P0001S
L1-7 nsp COIL INDUCTOR 0.5UH D330R50000000S
z
L100 963111010230S COIL LINE FILTER LF-4ZB-E273H 27mH D320402730020S
z
RL101 963682010370S RELAY HL31-1AT-5H 5V 1A G680050102020S
RLY1 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
①
.RELAY_A
RLY2-5 963682003410S RELAY HL3-2A-12S 12V 5A G680120503020S
R20-23 nsp R,CARBON FILM//22-J,1/5W-52RE-AX C00002206P520S
②
.RELAY_B
RLY2-5 963682002440S RELAY G5PA-28MC 12V G680120502050S
R20-23 nsp R,CARBON FILM//20-J,1/5W-52RE-AX C00002006P520S
CX100 nsp CN.WAFER 7.92MM
2112CIE3,1912E3,
1912E1C
L108202000220S
CX101 nsp CN.WIRE 370MM/5P L025371052050S
CX102 nsp CN.WAFER 7.92MM 35328-0263
2112CIE3,1912E3,
1912E1C
L108353280290S
CX102 nsp CN.WAFER 7.92MM LWBP1143-02P 1912E2,1912EA L108011430210S
CX104 nsp CN.WAFER 5P TUC-P05X L101100030510S
z
T100 963102100020S TRANS,SWITCHING EER2834 E060283405520S *
W100-103 nsp CN.WIRE 40MM/1P L025400012440S
nsp HOLDER,FUSE CLIP F100_1 G645000050010S
nsp HOLDER,FUSE CLIP F100_2 G645000050010S
nsp HOLDER,FUSE CLIP F101_1 G645000050010S
nsp HOLDER,FUSE CLIP F101_2 G645000050010S
nsp FUSE LABEL T1.6AL/250V
1912E2,1912EA,
1912E1C
5507000006790S
nsp FUSE LABEL T3.15AL/250V
1912E2,1912EA,
1912E1C
5507000006800S
f
f
f
NOTE : Two kinds of relays can be used.
Please choose suitable resistors to each kind of relay.
