Ref. No. Part No. Part Name Remarks Q'ty New
IC41 963243100070S
IC CPU MICRO PROCESS
(R5F56108VNFP)
2112CIE3,1912E3 8952191200010 *
IC41 nsp
IC CPU MICRO PROCESS
(R5F56108VNFP)
1912E2,1912EA,
1912E1C
-
U1 236810057606S IC LOGIC ADV3002BSTZ J040300205510S
U2 234810018506S IC LOGIC TC74VHC4052AFT J040744052080S
U4 nsp IC LOGIC ADV7844 HDMI J040784405510S
U6 943246012690S
IC MEMORY-RAM
(W9864G6JH-6)
CVIW9864G6JH-6
U7 963248100100S IC EN29LV160BB-70TIP 8952191200020 *
U8 nsp
IC ANALOG
ADSP21487KSWZ-3B3018
1912E3,1912E2,
1912EA,1912E1C
J080214875510S
U8 nsp
IC,ANALOG
ADSP21487KSWZ-3B3017
2112CIE3 J080214875520S
Q1 943214500020S TR 2SC 2SC3052 CVT2SC3052
Q3 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q4 943216500050S TR 2SC RT1N441C CVTRT1N441C
Q5 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q6,7 943216500050S TR 2SC RT1N441C CVTRT1N441C
Q8 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q9 943216500050S TR 2SC RT1N441C CVTRT1N441C
Q10 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q11-13 943216500050S TR 2SC RT1N441C CVTRT1N441C
Q14 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q15 943216500050S TR 2SC RT1N441C CVTRT1N441C
Q16 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q17-19 943216500050S TR 2SC RT1N441C CVTRT1N441C
Q20 00D2750110905 SEMI HN1K02FU J543102000020S
Q22 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q24 963219004200S CHIP FDC608PZ P-CH J543608000010S
Q25 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q26 943215500020S TR 2SA RT1P141C CVTRT1P141C
Q27 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q29 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q30 943215500020S TR 2SA RT1P141C CVTRT1P141C
Q31-39 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q40-43 943215500030S TR 2SA RT1P441C CVTRT1P441C
Q44 943216500020S TR 2SC RT1N141C CVTRT1N141C
TR1 943216500050S TR 2SC RT1N441C CVTRT1N441C
TR2 963219004200S CHIP FDC608PZ P-CH J543608000010S
TR3 00D2710326904 TR 2SA 2SA1954 J520195405510S
TR4 943216500020S TR 2SC RT1N141C CVTRT1N141C
TR5 00D2710326904 TR 2SA 2SA1954 J520195405510S
TR6 943216500020S TR 2SC RT1N141C CVTRT1N141C
TR7 943216500050S TR 2SC RT1N441C CVTRT1N441C
TR8 963219004200S CHIP FDC608PZ P-CH J543608000010S
TR9 00D2710326904 TR 2SA 2SA1954 J520195405510S
TR10 943216500020S TR 2SC RT1N141C CVTRT1N141C
TR11 943216500050S TR 2SC RT1N441C CVTRT1N441C
TR12 963219004200S CHIP FDC608PZ P-CH J543608000010S
TR14 943216500050S TR 2SC RT1N441C CVTRT1N441C
TR15 963219004200S CHIP FDC608PZ P-CH J543608000010S
TR16 00D2710326904 TR 2SA 2SA1954 J520195405510S
TR17 943216500020S TR 2SC RT1N141C CVTRT1N141C
TR20 943216500050S TR 2SC RT1N441C CVTRT1N441C
TR21 963219004200S CHIP FDC608PZ P-CH J543608000010S
TR22-28 943214500020S TR 2SC 2SC3052 CVT2SC3052
TR29,30 963212500030S TR 2SA ISA1530AC1 J520015301210S *
TR31 963219002180S TR 2SD2114KT146W J5232114K0010S
TR32,33 943214500020S TR 2SC 2SC3052 CVT2SC3052
TR34 943214500020S TR 2SC 2SC3052 2112CIE3 CVT2SC3052
TR35 943215500030S TR 2SA RT1P441C 2112CIE3 CVTRT1P441C
NOTE :
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.
NOTE : When replacing the 1912E2(EA) or E1C parts, use the 1912E3/2112CIE3 parts.
After replacing the parts, overwrite the rmware with the newest 1912E2(EA) or E1C version rmware.
