Denon AVR-2105 Service Manual

227
AVR-2105/885 / AVC-1890
C1190 00D 963 9006 405 Electrolytic 2.2uF/50V
C1191 00D 963 9005 257 Mylar film 0.022uF/50V
C1192 00D 960 9010 094 Ceramic chip 0.01uF/50V
C1193 00D 963 9006 405 Electrolytic 2.2uF/50V
C1194 00D 963 0144 609 Ceramic chip 12pF/50V
C1195 00D 963 0144 900 Mylar film 0.0022uF/50V
C1196 00D 963 9005 972 Electrolytic 0.22uF/50V
C1200 00D 963 9005 202 Mylar film 0.1uF/50V
C1211 00D 963 9005 312 Electrolytic 100uF/10V
C1212 00D 963 9005 312 Electrolytic 100uF/10V
C1213 00D 963 9006 382 Electrolytic 22uF/25V
C1214 00D 963 9006 382 Electrolytic 22uF/25V
C1216 00D 963 9005 312 Electrolytic 100uF/10V
C1217 00D 963 9006 382 Electrolytic 22uF/25V
C1218 00D 963 9006 382 Electrolytic 22uF/25V
C603D 00D 963 9005 312 Electrolytic 100uF/10V
C606D 00D 963 9004 753 Ceramic chip 0.047uF/50V
C607D 00D 963 9004 575 Ceramic chip 100pF/50V
C608D 00D 963 9004 575 Ceramic chip 100pF/50V
C609D 00D 963 9004 575 Ceramic chip 100pF/50V
C611D 00D 963 0157 706 Ceramic chip 0.022uF/50V *
C615D 00D 963 9004 575 Ceramic chip 100pF/50V
C616D 00D 963 9004 575 Ceramic chip 100pF/50V
C617D 00D 963 9004 575 Ceramic chip 100pF/50V
C618D 00D 963 0130 105 Mylar film 1uF/63V
C619D 00D 963 9004 753 Ceramic chip 0.047uF/50V
C620D 00D 960 9010 094 Ceramic chip 0.01uF/50V
C629D 00D 963 9004 575 Ceramic chip 100pF/50V
C630D 00D 963 9004 575 Ceramic chip 100pF/50V
C631D 00D 963 9004 575 Ceramic chip 100pF/50V
C642D 00D 963 9004 575 Ceramic chip 100pF/50V
C643D 00D 963 9004 575 Ceramic chip 100pF/50V
C644D 00D 963 9004 575 Ceramic chip 100pF/50V
C645D 00D 963 9006 379 Electrolytic 1uF/50V
C646D 00D 963 9003 372 Carbon chip 0 ohm 1/16W
C647D 00D 963 9003 372 Carbon chip 0 ohm 1/16W
C648D 00D 963 9003 372 Carbon chip 0 ohm 1/16W
C649D 00D 963 9003 372 Carbon chip 0 ohm 1/16W
C650D 00D 963 9003 372 Carbon chip 0 ohm 1/16W
C901 00D 963 9004 575 Ceramic chip 100pF/50V
C902 00D 963 9004 575 Ceramic chip 100pF/50V
C903 00D 963 9004 575 Ceramic chip 100pF/50V
C904 00D 963 9004 575 Ceramic chip 100pF/50V
C905 00D 963 9004 575 Ceramic chip 100pF/50V
C906 00D 963 9004 575 Ceramic chip 100pF/50V
C951 00D 963 9004 575 Ceramic chip 100pF/50V
C952 00D 963 9004 575 Ceramic chip 100pF/50V
C953 00D 963 9003 372 Carbon chip 0 ohm 1/16W
OTHER PARTS GROUP
CN553D 00D 963 0097 206 8P connector socket (TUC-P)
CN557D 00D 963 0086 709 11P connector socket (TUC-P)
CN602D 00D 963 0097 303 15P connector socket (TUC-P)
J209RM 00D 963 9003 372 Carbon chip 0 ohm 1/16W
JK103D 00D 963 0085 108 D connector
JK104D 00D 963 0085 108 D connector
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
