Denon AVR-2105 Service Manual

228
AVR-2105/885 / AVC-1890
JK105D 00D 963 0085 108 D connector
JK106D 00D 963 0085 108 D connector
RLY601D 00D 963 0146 704 Relay (RSB6S DC6V)
RLY602D 00D 963 0146 704 Relay (RSB6S DC6V)
RLY603D 00D 963 0146 704 Relay (RSB6S DC6V)
RLY604D 00D 963 0146 704 Relay (RSB6S DC6V)
RLY605D 00D 963 0146 704 Relay (RSB6S DC6V)
RLY606D 00D 963 0146 704 Relay (RSB6S DC6V)
RLY607D 00D 963 0146 704 Relay (RSB6S DC6V)
RLY608D 00D 963 0146 704 Relay (RSB6S DC6V)
XTAL1150 00D 963 0145 404 Crystal 3.579545MHZ
XTAL1151 00D 963 0145 501 Resonator CSB503F2
- 00D 963 0158 501 2P pin jack 1 *
- 00D 960 0268 803 6P pin jack 1
Ref. No. Part No. Part Name Remarks New
