Denon AVR-2105 Service Manual

56
AVR-2105/885 / AVC-1890
Q1014 00D 960 0068 207 Transistor KTA1504Y
Q1015 00D 963 0120 801 Transistor KRC102S
Q1016 00D 960 0068 207 Transistor KTA1504Y
Q1017 00D 960 0068 207 Transistor KTA1504Y
Q1018 00D 960 0068 207 Transistor KTA1504Y
Q1019 00D 960 0068 207 Transistor KTA1504Y
Q1020 00D 963 0066 606 Transistor KTC3875Y
Q1021 00D 963 0066 606 Transistor KTC3875Y
Q1022 00D 960 0068 207 Transistor KTA1504Y
Q1023 00D 963 0102 803 Transistor 2SA933S
Q1150 00D 963 0159 102 Transistor KRC111S *
Q1151 00D 960 0068 207 Transistor KTA1504Y
Q1152 00D 963 0159 102 Transistor KRC111S *
Q1153 00D 960 0068 207 Transistor KTA1504Y
Q1155 00D 963 0159 102 Transistor KRC111S *
Q1156 00D 960 0068 207 Transistor KTA1504Y
Q1157 00D 963 0159 102 Transistor KRC111S *
Q1158 00D 960 0068 207 Transistor KTA1504Y
Q207T 00D 960 0196 807 Transistor 2SK117Y
Q208T 00D 960 0196 807 Transistor 2SK117Y
Q209T 00D 960 0097 003 Transistor KRA104M
Q210T 00D 963 0121 004 Transistor KRC104M
Q551SW 00D 963 0044 301 Transistor KTC2875B
Q552SW 00D 963 0044 301 Transistor KTC2875B
Q601C 00D 963 0121 208 Transistor KRC107M
Q602C 00D 963 0121 208 Transistor KRC107M
Q603C 00D 963 0121 208 Transistor KRC107M
Q604C 00D 963 0121 208 Transistor KRC107M
Q605C 00D 960 0111 808 Transistor KRC107S
Q606 00D 963 0121 208 Transistor KRC107M
Q606C 00D 963 0102 803 Transistor 2SA933S
Q607C 00D 963 0120 801 Transistor KRC102S
Q608C 00D 963 0121 208 Transistor KRC107M
Q609C 00D 963 0121 208 Transistor KRC107M
Q610C 00D 963 0121 208 Transistor KRC107M
Q707M 00D 960 0097 508 Transistor KRC111M
D1000 00D 960 0197 000 Diode KDS160
D1001 00D 960 0197 000 Diode KDS160
D1002 00D 960 0197 000 Diode KDS160
D1003 00D 960 0197 000 Diode KDS160
D1004 00D 960 0197 000 Diode KDS160
D1005 00D 960 0197 000 Diode KDS160
D1012 00D 963 0020 309 Diode 1SS133T
D1014 00D 963 0020 309 Diode 1SS133T
D1150 00D 960 0197 000 Diode KDS160
D1151 00D 960 0197 000 Diode KDS160
D1152 00D 960 0197 000 Diode KDS160
D1153 00D 960 0197 000 Diode KDS160
D1154 00D 960 0197 000 Diode KDS160
D1155 00D 960 0197 000 Diode KDS160
D1156 00D 960 0095 500 Zener diode MTZJ5.1B
D205T 00D 960 0197 000 Diode KDS160
D207T 00D 960 0197 000 Diode KDS160
D251 00D 960 0197 000 Diode KDS160
D252 00D 960 0197 000 Diode KDS160
D253 00D 960 0197 000 Diode KDS160
D254 00D 960 0197 000 Diode KDS160
D255 00D 960 0197 000 Diode KDS160
D256 00D 960 0197 000 Diode KDS160
D601C 00D 960 0197 000 Diode KDS160
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
