Denon AVR-2105 Service Manual

57
AVR-2105/885 / AVC-1890
D602C 00D 960 0197 000 Diode KDS160
D603C 00D 960 0197 000 Diode KDS160
D604C 00D 960 0197 000 Diode KDS160
D605C 00D 960 0197 000 Diode KDS160
D606C 00D 960 0197 000 Diode KDS160
D607C 00D 960 0197 000 Diode KDS160
D608C 00D 960 0197 000 Diode KDS160
D609C 00D 960 0197 000 Diode KDS160
D610C 00D 960 0197 000 Diode KDS160
D611C 00D 960 0197 000 Diode KDS160
D612 00D 960 0197 000 Diode KDS160
D701B 00D 963 0020 309 Diode 1SS133T
D901 00D 960 0197 000 Diode KDS160
D902 00D 960 0197 000 Diode KDS160
D903 00D 960 0197 000 Diode KDS160
D904 00D 960 0197 000 Diode KDS160
ZD1000 00D 960 0095 500 Zener diode MTZJ5.1B
ZD1013 00D 960 0095 500 Zener diode MTZJ5.1B
ZD701M 00D 960 0095 500 Zener diode MTZJ5.1B
RESISTORS GROUP
R1031 00D 963 9005 639 Metal film 100 ohm 1W
R1038 00D 963 9005 639 Metal film 100 ohm 1W
R1059 00D 963 9005 639 Metal film 100 ohm 1W
R1095 00D 963 0018 007 Metal film 100 ohm 1/4W
R1140 00D 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R1163 00D 963 9005 639 Metal film 100 ohm 1W
R1166 00D 963 9005 639 Metal film 100 ohm 1W
R1193 00D 963 9005 639 Metal film 100 ohm 1W
R1198 00D 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R1199 00D 963 9005 639 Metal film 100 ohm 1W
R229T 00D 963 9005 639 Metal film 100 ohm 1W
R230T 00D 963 9005 639 Metal film 100 ohm 1W
R713B 00D 960 9004 301 Metal film 47 ohm 1/4W
R738M 00D 963 9005 338 Carbon chip 1.6 kohm 1/10W
VR608 00D 960 0091 601 Semi fixed resistor 1 kohm
VR609 00D 960 0091 601 Semi fixed resistor 1 kohm
VR610 00D 960 0091 601 Semi fixed resistor 1 kohm
CAPACITORS GROUP
C1000 00D 963 9006 382 Electrolytic 22uF/25V
C1001 00D 963 9006 382 Electrolytic 22uF/25V
C1002 00D 963 9005 312 Electrolytic 100uF/10V
C1003 00D 963 9004 753 Ceramic chip 0.047uF/50V
C1004 00D 963 9006 308 Electrolytic 10uF/50V
C1005 00D 963 9006 308 Electrolytic 10uF/50V
C1006 00D 963 9006 382 Electrolytic 22uF/25V
C1007 00D 963 9004 753 Ceramic chip 0.047uF/50V
C1008 00D 963 9006 382 Electrolytic 22uF/25V
C1009 00D 963 9006 308 Electrolytic 10uF/50V
C1010 00D 963 9006 405 Electrolytic 2.2uF/50V
C1011 00D 963 9006 405 Electrolytic 2.2uF/50V
C1013 00D 963 9006 382 Electrolytic 22uF/25V
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
