Denon AVR-2105 Service Manual

62
AVR-2105/885 / AVC-1890
C714L 00D 963 9006 476 Electrolytic 4.7uF/50V
C714R 00D 963 9006 476 Electrolytic 4.7uF/50V
C715L 00D 963 9004 737 Ceramic chip 0.022uF/25V
C715R 00D 963 9004 737 Ceramic chip 0.022uF/25V
C716L 00D 963 9006 308 Electrolytic 10uF/50V
C716R 00D 963 9006 308 Electrolytic 10uF/50V
C717L 00D 963 9004 601 Ceramic chip 220pF/50V
C717R 00D 963 9004 601 Ceramic chip 220pF/50V
C718L 00D 963 9006 421 Electrolytic 47uF/10V
C718R 00D 963 9006 421 Electrolytic 47uF/10V
C719L 00D 963 9006 379 Electrolytic 1uF/50V
C719R 00D 963 9006 379 Electrolytic 1uF/50V
C720L 00D 963 9003 152 Mylar film 0.068uF/100V
C720R 00D 963 9003 152 Mylar film 0.068uF/100V
C721L 00D 963 9003 152 Mylar film 0.068uF/100V
C721R 00D 963 9003 152 Mylar film 0.068uF/100V
C723L 00D 963 9006 308 Electrolytic 10uF/50V
C723M 00D 963 9006 379 Electrolytic 1uF/50V
C723R 00D 963 9006 308 Electrolytic 10uF/50V
C724L 00D 963 9004 698 Ceramic chip 0.01uF/50V
C724M 00D 963 9006 379 Electrolytic 1uF/50V
C724R 00D 963 9004 698 Ceramic chip 0.01uF/50V
C725 00D 963 9004 698 Ceramic chip 0.01uF/50V
C725M 00D 963 9006 379 Electrolytic 1uF/50V
C726 00D 963 9004 698 Ceramic chip 0.01uF/50V
C726M 00D9630157609 Ceramic chip 150pF/50V *
C727 00D 963 9006 308 Electrolytic 10uF/50V
C727M 00D 963 9004 575 Ceramic chip 100pF/50V
C728 00D 963 9006 308 Electrolytic 10uF/50V
C728M 00D9630157609 Ceramic chip 150pF/50V *
C729 00D 963 9004 708 Ceramic chip 0.1uF/50V
C729M 00D 963 9006 379 Electrolytic 1uF/50V
C730BL 00D 963 9004 575 Ceramic chip 100pF/50V
C730BR 00D 963 9004 575 Ceramic chip 100pF/50V
C730M 00D 963 9006 308 Electrolytic 10uF/50V
C731BL 00D 963 9004 698 Ceramic chip 0.01uF/50V
C731BR 00D 963 9004 698 Ceramic chip 0.01uF/50V
C737M 00D 963 9004 575 Ceramic chip 100pF/50V
C738M 00D 963 9004 698 Ceramic chip 0.01uF/50V
C901SW 00D 963 9006 476 Electrolytic 4.7uF/50V
C910 00D 963 9004 575 Ceramic chip 100pF/50V
C911 00D 960 9010 094 Ceramic chip 0.01uF/50V
C912 00D 963 9004 575 Ceramic chip 100pF/50V
C913 00D 963 9004 575 Ceramic chip 100pF/50V
C914 00D 963 9004 575 Ceramic chip 100pF/50V
C915 00D 963 9004 575 Ceramic chip 100pF/50V
C916 00D 963 9004 575 Ceramic chip 100pF/50V
C917 00D 960 9010 094 Ceramic chip 0.01uF/50V
C918 00D 963 9004 575 Ceramic chip 100pF/50V
C920 00D 963 9004 575 Ceramic chip 100pF/50V
OTHER PARTS GROUP
CB1000 00D 963 0120 908 Beads inductor
CB1001 00D 963 0120 908 Beads inductor
CB1002 00D 963 0115 609 Inductor 33uH
CB205 00D 963 0154 602 Beads inductor *
CN1000 00D 963 0086 505 7P connector socket (TUC-P)
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
