Denon AVR-2105 Service Manual

63
AVR-2105/885 / AVC-1890
CN1004 00D 963 0110 701 14P connector socket (TUC-P)
CN1150 00D 963 0086 505 7P connector socket (TUC-P)
CN1151 00D 963 0097 303 15P connector socket (TUC-P)
CN1154 00D 963 0097 303 15P connector socket (TUC-P)
CN403 00D 963 0086 709 11P connector socket (TUC-P)
CN508 00D 963 0159 306 9P connector cord *
CN509 00D 963 0159 209 7P connector cord *
CN557T 00D 963 0050 104 4P connector base
CN600 00D 963 0097 303 15P connector socket (TUC-P)
CN701 00D 963 0086 301 18P connector socket (TUC-P)
CN701M 00D 963 0160 104 4P connector cord *
CN703 00D 963 0086 505 7P connector socket (TUC-P)
CN805 00D 963 0097 206 8P connector socket (TUC-P)
CN806 00D 963 0086 204 19P connector socket (TUC-P)
CP556 00D 963 0060 903 15P connector base
JK704 00D 960 0188 103 2P pin jack
L1000 00D 963 0145 200 Inductor 27uH
L1001 00D 960 0128 008 Inductor 100uH
L1002 00D 963 0145 200 Inductor 27uH
L1003 00D 963 0120 908 Beads inductor
L1004 00D 963 0145 200 Inductor 27uH
L1005 00D 963 0145 103 Inductor 22uH
L1006 00D 960 0128 008 Inductor 100uH
L1007 00D 960 0128 008 Inductor 100uH
L1008 00D 963 0120 908 Beads inductor
RL701B 00D 963 0083 100 Relay (RSB12S DC12V)
RLY601 00D 963 0146 704 Relay (RSB6S DC6V)
RLY602 00D 963 0146 704 Relay (RSB6S DC6V)
RLY603 00D 963 0146 704 Relay (RSB6S DC6V)
RLY604 00D 963 0146 704 Relay (RSB6S DC6V)
RLY605 00D 963 0146 704 Relay (RSB6S DC6V)
RLY606 00D 963 0146 704 Relay (RSB6S DC6V)
RLY607 00D 963 0146 704 Relay (RSB6S DC6V)
RLY608 00D 963 0146 704 Relay (RSB6S DC6V)
XTAL1000 00D 963 0131 405 Crystal 14.318180MHZ
XTAL1150 00D 963 0145 404 Crystal 3.579545MHZ
XTAL1151 00D 963 0145 501 Resonator CSB503F2
- 00D 963 0101 707 Input cushion 1
- 00D 963 0094 102 PLATE INPUT 1
- 00D 963 0146 209 4P pin jack 2
- 00D 960 0268 803 6P pin jack 1
- 00D 963 0146 102 2P pin jack 2
- 00D 963 0146 209 4P pin jack 1
- 00D 963 0146 500 3P pin jack 1
- 00D 963 0146 306 6P pin jack 2
- 00D 963 0146 209 4P pin jack 2
- 00D 963 0158 200 Mini jack 1 *
Ref. No. Part No. Part Name Remarks New
