Denon AVR-2105 Service Manual

72
AVR-2105/885 / AVC-1890
C901H 00D 963 9004 533 Ceramic 0.001uF/50V
C902H 00D 963 9004 533 Ceramic 0.001uF/50V
C903H 00D 963 0020 202 Ceramic 0.1uF/50V
C904H 00D 960 9003 108 Ceramic 0.022uF/25V
C905H 00D 963 0020 202 Ceramic 0.1uF/50V
C906H 00D 963 9004 546 Ceramic 0.01uF/16V
C907H 00D 960 9006 202 Ceramic 0.01uF/50V
OTHER PARTS GROUP
CB903 00D 963 0154 602 Beads inductor *
CB904 00D 963 0154 602 Beads inductor *
CN901 00D 963 0160 201 3P connector cord *
CN931A 00D 963 0148 809 2P connector cord
CN992 00D 963 0160 007 4P connector cord *
! CP101 00D 960 0118 908 AC cord connector base
CP102 00D 960 0123 304 2P connector base
CP103 00D 960 0128 901 3P connector base
CP104 00D 960 0128 804 6P connector base
CP106 00D 960 0123 207 3P connector base
CP1151 00D 963 0097 507 15P connector base (TUC-P)
CP1153 00D 963 0097 507 15P connector base (TUC-P)
CP138A 00D 960 0123 207 3P connector base
CP3911 00D 963 0160 900 8P connector base *
CP392 00D 963 0048 909 3P connector base
CP501 00D 963 0086 806 9P connector base (TUC-P)
CP502 00D 963 0085 807 7P connector base (TUC-P)
CP503 00D 963 0085 807 7P connector base (TUC-P)
CP504 00D 963 0086 903 5P connector base (TUC-P)
CP505 00D 963 0087 708 12P connector base (TUC-P)
CP555 00D 963 0111 108 14P connector base (TUC-P)
CP556 00D 963 0087 805 11P connector base (TUC-P)
CP901 00D 963 0048 909 3P connector base
CP931 00D 963 0149 206 2P connector base(BLUE)
! F102 00D 963 0104 801 Fuse 3.15A
F102A 00D 960 0005 804 Fuse clip
F102B 00D 960 0005 804 Fuse clip
G901 - 1P contact Ass'y
GND101 00D 960 9006 600 Terminal
GND102 00D 960 9006 600 Terminal
GND103 00D 960 9006 600 Terminal
JK901 00D 963 0095 402 Head phone jack
L101C 00D 963 0049 005 Inductor 0.5uH
L101FL 00D 963 0049 005 Inductor 0.5uH
L101FR 00D 963 0049 005 Inductor 0.5uH
L101SL 00D 963 0049 005 Inductor 0.5uH
L101SR 00D 963 0049 005 Inductor 0.5uH
RLY101 00D 960 0181 702 Relay (G5PA-28 24V)
RLY102 00D 960 0181 702 Relay (G5PA-28 24V)
RLY103 00D 960 0181 702 Relay (G5PA-28 24V)
RLY104 00D 960 0181 702 Relay (G5PA-28 24V)
Ref. No. Part No. Part Name Remarks New
