Denon AVR-2105 Service Manual

73
AVR-2105/885 / AVC-1890
RLY105 00D 963 0071 303 Relay (RSB24S 24V)
! RLY106 00D 960 0181 605 Relay (G5PA-1-8 12V)
RLY107 00D 960 0181 702 Relay (G5PA-28 24V)
SW391 00D 963 0045 708 Tact switch
SW393 00D 963 0045 708 Tact switch
SW901 00D 963 0045 708 Tact switch
SW901A 00D 963 0145 802 Push switch
TP101 00D 960 0161 405 3P connector base
TP102 00D 960 0161 405 3P connector base
TP103 00D 960 0161 405 3P connector base
TP104 00D 960 0161 405 3P connector base
TP105 00D 960 0161 405 3P connector base
VEC303 00D 963 0095 208 ENCODER SW
- - Heat sink 1
- - Heat sink 1
- 00D 963 0068 400 Capacitor cover 1
- 00D 963 0120 500 Fuse label 1
! - 00D 963 0094 937 Power trans. (Mini) 1
- 00D 963 0018 007 Screw (2S 3X8 ZNY/BH) 3
- 00D 963 0158 608 2P speaker terminal 1 *
- 00D 963 0119 906 8P speaker terminal 2
