Denon AVR-2105 Service Manual

76
AVR-2105/885 / AVC-1890
C312 00D 963 9004 753 Ceramic chip 0.047uF/50V
C314 00D 963 0021 900 Mylar film 0.047uF/100V
C315 00D 963 9006 379 Electrolytic 1uF/50V
C316 00D 963 9006 308 Electrolytic 10uF/50V
C317 00D963 9005 859 Electrolytic 47uF/16V
C318 00D 963 9005 419 Mylar film 0.047uF/63V
C319 00D 963 9006 434 Electrolytic 47uF/16V
C320 00D 963 9006 379 Electrolytic 1uF/50V
C321 00D 963 0021 900 Mylar film 0.047uF/100V
C322 00D 963 9006 434 Electrolytic 47uF/16V
C323 00D 963 9004 766 Mylar film 0.1uF/100V
C324 00D 963 9006 476 Electrolytic 4.7uF/50V
C325 00D 963 9004 575 Ceramic chip 100pF/50V
C326 00D 963 9006 382 Electrolytic 22uF/25V
C327 00D 963 9006 476 Electrolytic 4.7uF/50V
C329 00D 963 9006 531 Electrolytic 22uF/16V
C330 00D 963 9006 531 Electrolytic 22uF/16V
C340 00D 963 9004 575 Ceramic chip 100pF/50V
C341 00D 963 9004 575 Ceramic chip 100pF/50V
C347 00D 963 9004 708 Ceramic chip 0.1uF/50V
C348 00D 963 9004 708 Ceramic chip 0.1uF/50V
C354 00D 963 9004 708 Ceramic chip 0.1uF/50V
OTHER PARTS GROUP
BD205 00D 963 0050 502 Chip emifil
BD206 00D 963 0050 502 Chip emifil
BD207 00D 963 0154 602 Beads inductor *
BD208 00D 963 0154 602 Beads inductor *
BD209 00D 963 0154 602 Beads inductor *
BD250 00D 963 0154 602 Beads inductor *
BD301 00D 963 0050 502 Chip emifil
BD303 00D 963 0050 502 Chip emifil
BD304 00D 963 0050 502 Chip emifil
CB202 00D 963 0154 602 Beads inductor *
CB203 00D 963 0154 602 Beads inductor *
CB205 00D 963 0154 602 Beads inductor *
CB207 00D 963 0154 602 Beads inductor *
CB208 00D 963 0154 602 Beads inductor *
CN201 00D 963 0159 801 5P SHIELD WIRE *
CN302 00D 963 0160 502 8P connector cord *
CN303 00D 963 0160 308 3P connector cord *
CN605 00D 963 0159 908 3P connector cord *
CN606 00D 963 0159 607 4P connector cord *
CP1000 00D 963 0085 807 7P connector base (TUC-P)
CP1001 00D 963 0111 108 14P connector base (TUC-P)
CP1154 00D 963 0085 807 7P connector base (TUC-P)
CP1155 00D 963 0085 807 7P connector base (TUC-P)
CP301 00D 963 0161 103 23P FFC connector base *
CP301A 00D 963 0161 006 23P FFC connector base *
CP302 00D 963 0066 101 5P connector base
CP303 00D 963 0049 102 3P connector base
CP401 00D 963 0149 303 15P FFC connector base
CP404 00D 963 0087 805 11P connector base (TUC-P)
CP551 00D 963 0087 601 8P connector base (TUC-P)
CP552 00D 963 0087 504 19P connector base (TUC-P)
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
