Denon AVR-2105 Service Manual

77
AVR-2105/885 / AVC-1890
CP605 00D 963 0048 909 3P connector base
CP606 00D 963 0050 104 4P connector base
CP701 00D 963 0087 601 18P connector base (TUC-P)
CP703 00D 963 0087 805 11P connector base (TUC-P)
CP705 00D 963 0087 601 8P connector base (TUC-P)
CP706 00D 963 0087 601 8P connector base (TUC-P)
CP801 00D 963 0087 601 18P connector base (TUC-P)
CP802 00D 963 0087 504 19P connector base (TUC-P)
CP803 00D 960 0239 609 13P connector base (TUC-P)
CP804 00D 963 0087 504 19P connector base (TUC-P)
G903 - 1P contact Ass'y
GND01 00D 960 9006 600 Terminal
GND02 00D 960 9006 600 Terminal
GP301 - 1P contact Ass'y
GP301 - 1P contact Ass'y
J326 00D 963 9003 372 Carbon chip 0 ohm 1/16W
JIG601 00D 960 0123 605 13P connector base
JP353 00D 963 9003 372 Carbon chip 0 ohm 1/16W
L301 00D 960 0010 307 Inductor 10uH
L3010 00D 960 0215 908 Inductor 4.7uH
L302 00D 960 0128 008 Inductor 100uH
SW301C 00D 963 0045 708 Tact switch
SW302A 00D 963 0095 305 Tact switch
SW302B 00D 963 0095 305 Tact switch
SW302C 00D 963 0045 708 Tact switch
SW303A 00D 963 0095 305 Tact switch
SW303B 00D 963 0095 305 Tact switch
SW303C 00D 963 0045 708 Tact switch
SW304A 00D 963 0095 305 Tact switch
SW304B 00D 963 0095 305 Tact switch
SW304C 00D 963 0045 708 Tact switch
SW305A 00D 963 0095 305 Tact switch
SW305B 00D 963 0045 708 Tact switch
SW305C 00D 963 0045 708 Tact switch
SW306A 00D 963 0095 305 Tact switch
SW306B 00D 963 0095 305 Tact switch
SW306C 00D 963 0045 708 Tact switch
SW307A 00D 963 0095 305 Tact switch
SW307C 00D 963 0045 708 Tact switch
SW308A 00D 963 0095 305 Tact switch
SW308C 00D 963 0045 708 Tact switch
SW309A 00D 963 0095 305 Tact switch
SW309C 00D 963 0045 708 Tact switch
VEC301 00D 963 0095 208 ENCODER SW
VEC302 00D 963 0095 208 ENCODER SW
X201 00D 960 0181 003 Resonator CST12.0MTW-TF01
X202 00D 963 0099 505 Crystal 4.332MHz
- - Heat sink 1
- 00D 963 0018 007 Screw (2S 3X8 ZNY/BH) 1
- 00D 960 0184 408 FLT holder 1
