Page #41 background imageLoading...
Page #41 background image
41
AVR-2106/886
C107FR 00D 963 9003 097 C,FILM 0.1UF-K/250V
C107SL 00D 963 9003 097 C,FILM 0.1UF-K/250V
C107SR 00D 963 9003 097 C,FILM 0.1UF-K/250V
C131 00D 963 9003 097 C,FILM 0.1UF-K/250V
C132 00D 963 9003 097 C,FILM 0.1UF-K/250V
C133 00D 963 9003 097 C,FILM 0.1UF-K/250V
C134 00D 963 9003 097 C,FILM 0.1UF-K/250V
C135 00D 963 9003 097 C,FILM 0.1UF-K/250V
C136 00D 254 6256 002 CE68W1J123M(DL)VNN
C137 00D 254 6256 002 CE68W1J123M(DL)VNN
C138 00D 963 9005 749 C,ELECT 1UF-M/50V
C138A 00D 963 9003 097 C,FILM 0.1UF-K/250V
C141 00D 963 0021 900 C,FILM 0.047UF-J/100V
C142 00D 963 0021 900 C,FILM 0.047UF-J/100V
C143 00D 963 0021 900 C,FILM 0.047UF-J/100V
C144 00D 963 0217 109 C,ELECT 3300UF-M/35V
C145 00D 963 9003 123 C,ELECT 1000UF-M/35V
C146 00D 963 9005 749 C,ELECT 1UF-M/50V
C148 00D 963 9005 749 C,ELECT 1UF-M/50V
C150 00D 963 0021 900 C,FILM 0.047UF-J/100V
C151 00D 963 0021 900 C,FILM 0.047UF-J/100V
C152 00D 963 0021 900 C,FILM 0.047UF-J/100V
C153 00D 963 0021 104 C,ELECT 6800UF-M/16V
C154 00D 963 0234 205 C,ELECT 10UF-M/50V
C155 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C157 00D 963 9005 749 C,ELECT 1UF-M/50V
C158 00D 963 0217 002 C,ELECT 3300UF-M/16V
C159 00D 963 9005 749 C,ELECT 1UF-M/50V
C161 00D 963 0234 205 C,ELECT 10UF-M/50V
C171 00D 960 9009 911 C,ELECT 100UF-M/10V
C171A 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C171B 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C171C 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C171D 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C172 00D 963 9005 833 C,ELECT 220UF-M/6.3V
C173 00D 963 9005 833 C,ELECT 220UF-M/6.3V
C174 00D 963 0234 205 C,ELECT 10UF-M/50V
C175 00D 963 9006 544 C,ELECT 22UF-M/25V
C176 00D 963 9005 749 C,ELECT 1UF-M/50V
C177 00D 963 9005 749 C,ELECT 1UF-M/50V
C178 00D 963 0157 900 C,ELECT 470UF-M/63V
C179 00D 963 9005 833 C,ELECT 220UF-M/6.3V
! C181 00D 963 9006 191 C,CERAMIC AC13F472MDOA
C182 00D 963 0234 302 C,ELECT 10UF-M/100V
C191 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C192 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C193 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C194 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C195 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C196 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C197 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C198 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C198C 00D 963 0024 703 C,FILM 0.01UF-J/100V
C198FL 00D 963 0024 703 C,FILM 0.01UF-J/100V
C198FR 00D 963 0024 703 C,FILM 0.01UF-J/100V
C198SBL 00D 963 0024 703 C,FILM 0.01UF-J/100V
C198SBR 00D 963 0024 703 C,FILM 0.01UF-J/100V
C198SL 00D 963 0024 703 C,FILM 0.01UF-J/100V
C198SR 00D 963 0024 703 C,FILM 0.01UF-J/100V
C199 00D 963 0233 400 C,CERAMIC 2200PF-K/16V
C199FL 00D 963 0024 703 C,FILM 0.01UF-J/100V
C199FR 00D 963 0024 703 C,FILM 0.01UF-J/100V
C331 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C332 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C901H 00D 963 0233 206 C,CERAMIC 0.001UF-K/50V
C902H 00D 963 0233 206 C,CERAMIC 0.001UF-K/50V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
