Denon AVR-2106 Service Manual

42
AVR-2106/886
C905H 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C906H 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
OTHER PARTS GROUP
CB903 nsp 00D 963 0154 602 BEAD,COIL
CLAMP101 nsp 00D 960 0260 005 CLAMP WIRE (L=50)
CN901 nsp 00D 963 0160 201 CN,WIRE 250MM/3P
CN931A nsp 00D 963 0148 809 CN,WIRE 350MM/2P
CN992 nsp 00D 963 0235 602 CN,WIRE 270MM/4P
CP101 nsp 00D 960 0118 908 CN.WAFER 2P
CP102 nsp 00D 960 0123 304 CN.WAFER 2P
CP103 nsp 00D 963 0066 208 CN.WAFER 3P
CP104 nsp 00D 960 0128 804 CN.WAFER 6P
CP105 nsp 00D 963 0149 109 CN.WAFER 2P (BLACK)
CP106 nsp 00D 960 0123 207 CN.WAFER 3P
CP1151 nsp 00D 963 0097 507 CN.WAFER 15
CP1153 nsp 00D 963 0097 507 CN.WAFER 15
CP138A nsp 00D 960 0123 207 CN.WAFER 3P
CP391 nsp 00D 963 0160 900 CN.WAFER 8P
CP392 nsp 00D 963 0235 806 CN.WAFER 3P
CP501 nsp 00D 963 0206 505 CN.WAFER 9P
CP502 nsp 00D 963 0206 408 CN.WAFER 7P
CP503 nsp 00D 963 0206 408 CN.WAFER 7P
CP504 nsp 00D 963 0206 301 CN.WAFER 5P
CP505 nsp 00D 963 0235 709 CN.WAFER 12P
CP555 nsp 00D 963 0111 108 CN.WAFER 14P
CP556 nsp 00D 963 0087 805 CN.WAFER 11P
CP901 nsp 00D 963 0235 806 CN.WAFER 3P
CP931 nsp 00D 963 0149 206 CN.WAFER 2P (BLUE)
! F102 00D 963 0236 106 FUSE T8A/250V
G901 - RING,TER WIRE 120MM/1P
GND101 - TERMINAL, EARTH
GND102 - TERMINAL, EARTH
GND103 - TERMINAL, EARTH
L101C nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101FL nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101FR nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101SL nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101SR nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
RLY101 00D 960 0181 702 RELAY, G5PA-28 24V 5A
RLY102 00D 960 0181 702 RELAY, G5PA-28 24V 5A
RLY103 00D 960 0181 702 RELAY, G5PA-28 24V 5A
RLY104 00D 960 0181 702 RELAY, G5PA-28 24V 5A
RLY105 00D 963 0218 506 RELAY, BC3-24
RLY106 00D 963 0218 205 RELAY, G5PA-1 DC9V 250V/5A
RLY107 00D 960 0181 702 RELAY, G5PA-28 24V 5A
SW391 00D 963 0200 103 SW,TACT SKHV10920A
SW393 00D 963 0200 103 SW,TACT SKHV10920A
SW901 00D 963 0200 103 SW,TACT SKHV10920A
! SW901A 00D 963 0145 802 SW,PUSH SDDL-005-S(C-UL)
TP101 nsp 00D 960 0161 405 CN.WAFER 3P
TP102 nsp 00D 960 0161 405 CN.WAFER 3P
TP103 nsp 00D 960 0161 405 CN.WAFER 3P
TP104 nsp 00D 960 0161 405 CN.WAFER 3P
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
