Denon AVR-2106 Service Manual

55
AVR-2106/886
D1156 00D 960 0095 500 D,ZENER MTZJ5.1B
ZD701M 00D 960 0095 500 D,ZENER MTZJ5.1B
ZD1000 00D 960 0095 500 D,ZENER MTZJ5.1B
ZD1002 00D 963 0219 903 D,ZENER MTZJ16B for AVR2106E3
ZD1003 00D 963 0219 903 D,ZENER MTZJ16B for AVR2106E3
ZD1013 00D 960 0095 500 D,ZENER MTZJ5.1B
RESISTORS GROUP
R229T 00D 963 9005 639 R,METAL FILM 100-J,1W
R230T 00D 963 9005 639 R,METAL FILM 100-J,1W
R713B 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R740 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R1031 00D 963 9005 639 R,METAL FILM 100-J,1W
R1038 00D 963 9005 639 R,METAL FILM 100-J,1W
R1059 00D 963 9005 639 R,METAL FILM 100-J,1W
R1095 00D 960 9003 807 R,METAL FILM 100-J,1/4W
R1140 00D 963 9003 068 R,METAL FILM 4.7-J,1/4W
R1163 00D 963 9005 639 R,METAL FILM 100-J,1W
R1166 00D 963 9005 639 R,METAL FILM 100-J,1W
R1193 00D 963 9005 639 R,METAL FILM 100-J,1W
R1198 00D 963 9003 068 R,METAL FILM 4.7-J,1/4W
R1199 00D 963 9005 639 R,METAL FILM 100-J,1W
VR608 00D 960 0091 601 VR,SEMI 1KB
VR609 00D 960 0091 601 VR,SEMI 1KB
VR610 00D 960 0091 601 VR,SEMI 1KB
CAPACITORS GROUP
C211SW nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C212SW nsp 00D 963 0233 808 C,CERAMIC CHIP 47PF-J/50V
C213FL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C213FR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C213T nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C214T nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C215T nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C216T nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C217T nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C218FL nsp 00D 963 0223 805 C,CERAMIC CHIP 33PF-J/50V
C218FR nsp 00D 963 0223 805 C,CERAMIC CHIP 33PF-J/50V
C218T 00D 963 9005 749 C,ELECT 1UF-M/50V
C219FL 00D 963 0234 205 C,ELECT 10UF-M/50V
C219FR 00D 963 0234 205 C,ELECT 10UF-M/50V
C219SW 00D 963 0234 205 C,ELECT 10UF-M/50V
C219T 00D 963 9005 749 C,ELECT 1UF-M/50V
C220T 00D 963 0234 205 C,ELECT 10UF-M/50V
C223C 00D 963 9006 544 C,ELECT 22UF-M/25V
C223FL 00D 963 9006 544 C,ELECT 22UF-M/25V
C223FR 00D 963 9006 544 C,ELECT 22UF-M/25V
C223SBL 00D 963 9006 544 C,ELECT 22UF-M/25V
C223SBR 00D 963 9006 544 C,ELECT 22UF-M/25V
C223SL 00D 963 9006 544 C,ELECT 22UF-M/25V
C223SR 00D 963 9006 544 C,ELECT 22UF-M/25V
C223SW 00D 963 9006 544 C,ELECT 22UF-M/25V
C225T 00D 963 9005 749 C,ELECT 1UF-M/50V
C226T 00D 963 9005 749 C,ELECT 1UF-M/50V
C227T 00D 963 0234 205 C,ELECT 10UF-M/50V
C228T 00D 963 9005 862 C,ELECT 47UF-M/16V
C229T 00D 963 9005 862 C,ELECT 47UF-M/16V
C230T 00D 963 0234 205 C,ELECT 10UF-M/50V
C231C 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C231FL 00D 963 9006 214 C,ELECT 3.3UF-M/50V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
