Denon AVR-2106 Service Manual

56
AVR-2106/886
C231FR 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C231SBL 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C231SBR 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C231SL 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C231SR 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C231SW 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C231T 00D 963 0234 205 C,ELECT 10UF-M/50V
C232C nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232FL nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232FR nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232SBL nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232SBR nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232SL nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232SR nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232SW nsp 00D 960 9010 104 C,CERAMIC CHIP 5PF-C/50V
C232T 00D 963 9005 862 C,ELECT 47UF-M/16V
C233 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C233T 00D 963 9005 862 C,ELECT 47UF-M/16V
C234 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C234T 00D 963 9005 862 C,ELECT 47UF-M/16V
C235T 00D 963 9005 862 C,ELECT 47UF-M/16V
C236 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C236T 00D 963 9005 862 C,ELECT 47UF-M/16V
C237 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C237T 00D 963 9005 862 C,ELECT 47UF-M/16V
C238C 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C238FL 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C238FR 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C238SBL 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C238SBR 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C238SL 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C238SR 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C238SW 00D 963 9006 214 C,ELECT 3.3UF-M/50V
C239T nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C240 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C240T 00D 963 9005 749 C,ELECT 1UF-M/50V
C241 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C241T 00D 963 0234 205 C,ELECT 10UF-M/50V
C243T 00D 963 9005 749 C,ELECT 1UF-M/50V
C244T 00D 963 9005 749 C,ELECT 1UF-M/50V
C245T 00D 963 9005 749 C,ELECT 1UF-M/50V
C246T 00D 963 0234 205 C,ELECT 10UF-M/50V
C247T nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C248T 00D 963 9005 749 C,ELECT 1UF-M/50V
C249T nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C250T nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C251 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C252 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C253 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C602C 00D 963 9005 749 C,ELECT 1UF-M/50V
C605C nsp 00D 963 0223 009 R,CHIP 0-J,1/16W
C606C nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C617C nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C618C 00D 963 0199 308 C,FILM 1UF-J/63V
C619C nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C701BL 00D 960 9010 010 C,ELECT 4.7UF-M/50V
C701BR 00D 960 9010 010 C,ELECT 4.7UF-M/50V
C702BL nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C702BR nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C702L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C702R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C703BL 00D 963 0234 205 C,ELECT 10UF-M/50V
C703BR 00D 963 0234 205 C,ELECT 10UF-M/50V
C703L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C703R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C704BL 00D 963 0234 205 C,ELECT 10UF-M/50V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
