Denon AVR-2106 Service Manual

57
AVR-2106/886
C704BR 00D 963 0234 205 C,ELECT 10UF-M/50V
C704L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C704R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C705L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C705R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C706L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C706R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C707L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C707R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C708L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C708R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C709L 00D 963 0234 205 C,ELECT 10UF-M/50V
C709R 00D 963 0234 205 C,ELECT 10UF-M/50V
C710L nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C710R nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C711L 00D 963 9006 557 C,ELECT 220UF-M/6.3V
C711R 00D 963 9006 557 C,ELECT 220UF-M/6.3V
C712L 00D 963 0216 605 C,FILM 0.024UF-J/50V
C712R 00D 963 0216 605 C,FILM 0.024UF-J/50V
C713L 00D 960 9008 695 C,FILM 0.0068UF-J/100V
C713R 00D 960 9008 695 C,FILM 0.0068UF-J/100V
C714L 00D 960 9010 010 C,ELECT 4.7UF-M/50V
C714R 00D 960 9010 010 C,ELECT 4.7UF-M/50V
C715L nsp 00D 963 0224 202 C,CERAMIC CHIP 0.022UF-K/25V
C715R nsp 00D 963 0224 202 C,CERAMIC CHIP 0.022UF-K/25V
C716L 00D 963 0234 205 C,ELECT 10UF-M/50V
C716R 00D 963 0234 205 C,ELECT 10UF-M/50V
C717L nsp 00D 963 0233 604 C,CERAMIC CHIP 220PF-J/50V
C717R nsp 00D 963 0233 604 C,CERAMIC CHIP 220PF-J/50V
C718L 00D 963 9005 862 C,ELECT 47UF-M/16V
C718R 00D 963 9005 862 C,ELECT 47UF-M/16V
C719L 00D 963 9005 749 C,ELECT 1UF-M/50V
C719R 00D 963 9005 749 C,ELECT 1UF-M/50V
C723M 00D 963 9005 749 C,ELECT 1UF-M/50V
C724M 00D 963 9005 749 C,ELECT 1UF-M/50V
C725 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C725M 00D 963 9005 749 C,ELECT 1UF-M/50V
C726 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C726M nsp 00D 963 0157 609 C,CERAMIC CHIP 150PF-J/50V
C727 00D 963 0234 205 C,ELECT 10UF-M/50V
C727M nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C728 00D 963 0234 205 C,ELECT 10UF-M/50V
C728M nsp 00D 963 0157 609 C,CERAMIC CHIP 150PF-J/50V
C729 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C729M 00D 963 9005 749 C,ELECT 1UF-M/50V
C730 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C730BL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C730BR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C730M 00D 963 0234 205 C,ELECT 10UF-M/50V
C731 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C731BL nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C731BR nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C732 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C737M nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C738M nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C929SW5 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V for AVR2106E3
C1000 00D 963 9006 544 C,ELECT 22UF-M/25V
C1001 00D 963 9006 544 C,ELECT 22UF-M/25V
C1002 00D 960 9009 911 C,ELECT 100UF-M/10V
C1003 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1004 00D 963 0234 205 C,ELECT 10UF-M/50V
C1005 00D 963 0234 205 C,ELECT 10UF-M/50V
C1006 00D 963 9006 544 C,ELECT 22UF-M/25V
C1007 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1008 00D 963 9006 544 C,ELECT 22UF-M/25V
C1009 00D 963 0234 205 C,ELECT 10UF-M/50V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
