Denon AVR-2106 Service Manual

58
AVR-2106/886
C1010 00D 963 9006 117 C,ELECT 2.2UF-M/50V
C1011 00D 963 9006 117 C,ELECT 2.2UF-M/50V
C1013 00D 963 9006 544 C,ELECT 22UF-M/25V
C1014 00D 963 0234 205 C,ELECT 10UF-M/50V
C1015 00D 960 9009 911 C,ELECT 100UF-M/10V
C1016 nsp 00D 963 9006 146 C,CERAMIC CHIP 560PF-J/50V
C1017 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C1018 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C1019 00D 963 0234 205 C,ELECT 10UF-M/50V
C1020 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C1022 00D 963 0234 205 C,ELECT 10UF-M/50V
C1023 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C1024 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1026 00D 963 0234 205 C,ELECT 10UF-M/50V
C1027 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C1028 00D 960 9009 911 C,ELECT 100UF-M/10V
C1029 00D 963 9006 544 C,ELECT 22UF-M/25V
C1030 00D 963 9005 862 C,ELECT 47UF-M/16V
C1031 00D 963 0234 205 C,ELECT 10UF-M/50V
C1032 00D 963 9006 544 C,ELECT 22UF-M/25V
C1033 nsp 00D 963 0144 609 C,CERAMIC CHIP 12PF-J/50V
C1034 nsp 00D 963 9004 591 C,CERAMIC CHIP 22PF-J/50V
C1035 00D 963 9006 544 C,ELECT 22UF-M/25V
C1036 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1037 00D 963 0234 205 C,ELECT 10UF-M/50V
C1038 00D 963 9006 544 C,ELECT 22UF-M/25V
C1039 nsp 00D 963 9006 528 C,CERAMIC CHIP 20PF-J/50V
C1040 00D 963 9005 749 C,ELECT 1UF-M/50V
C1041 nsp 00D 963 0224 202 C,CERAMIC CHIP 0.022UF-K/25V
C1042 00D 963 9005 862 C,ELECT 47UF-M/16V
C1043 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1044 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1045 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1046 nsp 00D 963 9004 672 C,CERAMIC CHIP 680pF-J 50V
C1047 00D 963 0144 706 C,FILM 0.01UF-J/50V
C1048 00D 960 9009 911 C,ELECT 100UF-M/10V
C1049 nsp 00D 963 9006 528 C,CERAMIC CHIP 20PF-J/50V
C1050 nsp 00D 963 0144 609 C,CERAMIC CHIP 12PF-J/50V
C1051 nsp 00D 963 9004 591 C,CERAMIC CHIP 22PF-J/50V
C1052 00D 963 0234 205 C,ELECT 10UF-M/50V
C1053 00D 963 0234 205 C,ELECT 10UF-M/50V
C1054 nsp 00D 963 9005 998 C,CERAMIC CHIP 24PF-J/50V
C1055 00D 963 9006 544 C,ELECT 22UF-M/25V
C1056 00D 963 9005 749 C,ELECT 1UF-M/50V
C1057 nsp 00D 963 9005 998 C,CERAMIC CHIP 24PF-J/50V
C1058 00D 963 0255 608 C,ELECT 33UF-M/25V *
C1059 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1060 00D 963 9006 544 C,ELECT 22UF-M/25V
C1061 nsp 00D 963 0129 909 C,CERAMIC CHIP 1200PF-K/50V
C1062 00D 960 9009 911 C,ELECT 100UF-M/10V
C1063 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1064 00D 963 9006 544 C,ELECT 22UF-M/25V
C1065 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1066 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1067 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1068 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1069 00D 963 9006 544 C,ELECT 22UF-M/25V
C1070 00D 960 9009 911 C,ELECT 100UF-M/10V
C1071 00D 963 9005 749 C,ELECT 1UF-M/50V
C1072 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1073 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1074 00D 960 9009 911 C,ELECT 100UF-M/10V
C1075 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1076 00D 963 9006 544 C,ELECT 22UF-M/25V
C1077 00D 963 9006 544 C,ELECT 22UF-M/25V
C1078 00D 960 9010 023 C,ELECT 0.47UF-M/50V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
