Denon AVR-2106 Service Manual

59
AVR-2106/886
C1079 nsp 00D 963 0144 609 C,CERAMIC CHIP 12PF-J/50V
C1080 nsp 00D 963 0224 202 C,CERAMIC CHIP 0.022UF-K/25V
C1081 00D 963 9005 862 C,ELECT 47UF-M/16V
C1082 nsp 00D 963 9004 591 C,CERAMIC CHIP 22PF-J/50V
C1083 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1084 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1085 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1086 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C1100ML 00D 960 9010 010 C,ELECT 4.7UF-M/50V for AVR2106E3
C1100MR 00D 960 9010 010 C,ELECT 4.7UF-M/50V for AVR2106E3
C1101ML nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V for AVR2106E3
C1101MR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V for AVR2106E3
C1102ML 00D 960 9010 010 C,ELECT 4.7UF-M/50V for AVR2106E3
C1102MR 00D 960 9010 010 C,ELECT 4.7UF-M/50V for AVR2106E3
C1106T nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V for AVR2106E3
C1107T nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V for AVR2106E3
C1150 00D 963 9006 544 C,ELECT 22UF-M/25V
C1152 00D 963 9006 544 C,ELECT 22UF-M/25V
C1157 00D 963 9006 544 C,ELECT 22UF-M/25V
C1158 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1159 00D 963 9006 544 C,ELECT 22UF-M/25V
C1160 00D 963 0234 205 C,ELECT 10UF-M/50V
C1161 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C1162 00D 963 0234 205 C,ELECT 10UF-M/50V
C1163 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C1164 00D 963 9006 544 C,ELECT 22UF-M/25V
C1165 00D 963 9006 544 C,ELECT 22UF-M/25V
C1166 00D 963 9006 544 C,ELECT 22UF-M/25V
C1168 00D 963 9006 544 C,ELECT 22UF-M/25V
C1169 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C1170 00D 963 9006 036 C,ELECT 470UF-M/6.3V
C1171 00D 963 9006 544 C,ELECT 22UF-M/25V
C1172 00D 963 9006 544 C,ELECT 22UF-M/25V
C1173 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C1174 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1175 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1176 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1177 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1178 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1179 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1181 00D 963 0234 205 C,ELECT 10UF-M/50V
C1182 00D 963 0234 108 C,FILM 0.1UF-J/50V
C1183 00D 960 9010 023 C,ELECT 0.47UF-M/50V
C1184 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1185 00D 960 9009 911 C,ELECT 100UF-M/10V
C1186 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1187 00D 963 9005 862 C,ELECT 47UF-M/16V
C1188 00D 963 0234 205 C,ELECT 10UF-M/50V
C1189 00D 960 9010 023 C,ELECT 0.47UF-M/50V
C1190 00D 963 9006 117 C,ELECT 2.2UF-M/50V
C1191 00D 963 0141 709 C,FILM 0.022UF-J/50V
C1192 nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C1193 00D 963 9006 117 C,ELECT 2.2UF-M/50V
C1194 nsp 00D 963 0144 609 C,CERAMIC CHIP 12PF-J/50V
C1195 00D 963 0144 900 C,FILM 0.0022UF-J/50V
C1196 00D 963 9005 972 C,ELECT 0.22UF-M/50V
C1197 00D 963 9005 862 C,ELECT 47UF-M/16V
C1198 00D 963 0144 706 C,FILM 0.01UF-J/50V
C1199 00D 963 9005 862 C,ELECT 47UF-M/16V
C1200 00D 963 0234 108 C,FILM 0.1UF-J/50V
C1203 00D 963 9005 862 C,ELECT 47UF-M/16V
C1204 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1205 00D 963 9005 862 C,ELECT 47UF-M/16V
C1206 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C1211 00D 960 9009 911 C,ELECT 100UF-M/10V
C1212 00D 960 9009 911 C,ELECT 100UF-M/10V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
