Denon AVR-2106 Service Manual

60
AVR-2106/886
C1213 00D 963 9006 544 C,ELECT 22UF-M/25V
C1214 00D 963 9006 544 C,ELECT 22UF-M/25V
C1216 00D 960 9009 911 C,ELECT 100UF-M/10V
C1217 00D 963 9006 544 C,ELECT 22UF-M/25V
C1218 00D 963 9006 544 C,ELECT 22UF-M/25V
C1223 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
OTHER PARTS GROUP
BD1001 nsp 00D 963 0234 603 COIL,BEAD for AVR2106E3
BD1002 nsp 00D 963 0234 603 COIL,BEAD for AVR2106E3
CB1000 nsp 00D 963 0234 603 COIL,BEAD
CB1001 nsp 00D 963 0234 603 COIL,BEAD
CB1002 nsp 00D 963 0115 609 COIL,INDUCTOR 33UH
CN1001 nsp 00D 963 0086 505 CN.WAFER 7P
CN1003 nsp 00D 963 0097 206 CN.WAFER 8P for AVR2106E3
CN1004 nsp 00D 960 0239 900 CN.WAFER 13P
CN1151 nsp 00D 963 0097 303 CN.WAFER 15P
CN201 nsp 00D 963 0086 505 CN.WAFER 7P
CN202 nsp 00D 963 0086 505 CN.WAFER 7P
CN600 nsp 00D 963 0097 303 CN.WAFER 15P
CN701 nsp 00D 963 0086 709 CN.WAFER 11P
CN702 nsp 00D 963 0086 204 CN.WAFER 19P
CN703 nsp 00D 963 0110 701 CN.WAFER 14P
CN703M nsp 00D 963 0235 505 CN,WIRE 200MM/5P
CN704 nsp 00D 963 0086 709 CN.WAFER 11P
CP204 nsp 00D 963 0060 505 CN.WAFER 7P
CP205X nsp 00D 963 0097 604 CN.WAFER 6P
CP556 nsp 00D 963 0060 703 CN.WAFER 15P
CP701M nsp 00D 963 0066 101 CN.WAFER 5P
J604C nsp 00D 963 0223 009 R,CHIP 0-J,1/16W
JACK601D 00D 963 0146 306 TER,RCA 6PIN
JACK602D 00D 963 0146 306 TER,RCA 6PIN
JK201M 00D 963 0158 501 TER,RCA 2PIN for AVR2106E3
JK202RM 00D 963 0255 705 MINI-JACK, D3.5 for AVR2106E3 *
JK701 00D 960 0268 803 TER,RCA 6PIN
JK702 00D 963 0146 209 TER,RCA 4PIN
JK703 00D 963 0146 209 TER,RCA 4PIN
JK704 00D 960 0188 103 TER,RCA 2PIN
JK706V 00D 963 0218 001 TER,RCA 2PIN
JK707V 00D 963 0218 001 TER,RCA 2PIN
JK708V 00D 963 0218 108 TER,RCA 3PIN
L1000 nsp 00D 963 0145 200 COIL,INDUCTOR 27UH
L1001 nsp 00D 960 0128 008 COIL,INDUCTOR 100UH
L1002 nsp 00D 963 0145 200 COIL,INDUCTOR 27UH
L1003 nsp 00D 963 0234 603 COIL,BEAD
L1004 nsp 00D 963 0145 200 COIL,INDUCTOR 27UH
L1005 nsp 00D 963 0145 103 COIL,INDUCTOR 22UH
L1006 nsp 00D 960 0128 008 COIL,INDUCTOR 100UH
L1007 nsp 00D 960 0128 008 COIL,INDUCTOR 100UH
L1008 nsp 00D 963 0234 603 COIL,BEAD
RL701 00D 963 0218 409 RELAY BC3-12
RL701B 00D 963 0218 409 RELAY BC3-12
RLY601 00D 963 0218 302 RELAY BC3-6
RLY602 00D 963 0218 302 RELAY BC3-6
RLY603 00D 963 0218 302 RELAY BC3-6
RLY604 00D 963 0218 302 RELAY BC3-6
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
