63
AVR-2106/886
C211 00D 963 9005 804 C,ELECT 100UF-M/25V
C212 00D 963 9005 778 C,ELECT 10UF-M/50V
C212X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C213 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C213X nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C215 00D 960 9009 911 C,ELECT 100UF-M/10V for AVR2106E3
C215X 00D 963 9005 778 C,ELECT 10UF-M/50V
C216 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V for AVR2106E3
C216X 00D 963 9005 778 C,ELECT 10UF-M/50V
C217 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V for AVR2106E3
C217X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C218 00D 963 9005 927 C,ELECT 0.1UF-M/50V for AVR2106E3
C218X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C219 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C219X nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C220 00D 963 9005 927 C,ELECT 0.1UF-M/50V for AVR2106E3
C220X nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C221 00D 963 9005 927 C,ELECT 0.1UF-M/50V for AVR2106E3
C221X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C222 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V for AVR2106E3
C222X nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C223 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V for AVR2106E3
C223X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C224 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V for AVR2106E3
C224X 00D 963 9005 804 C,ELECT 100UF-M/25V
C225 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C225X 00D 963 9005 778 C,ELECT 10UF-M/50V
C226 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C226X 00D 960 9009 911 C,ELECT 100UF-M/10V
C227 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C227X nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C228 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C228X nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C229 00D 963 9005 927 C,ELECT 0.1UF-M/50V for AVR2106E3
C229X 00D 963 9005 778 C,ELECT 10UF-M/50V
C230 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C230X 00D 963 9005 778 C,ELECT 10UF-M/50V
C231X 00D 963 9005 927 C,ELECT 0.1UF-M/50V
C232X nsp 00D 963 9006 146 C,CERAMIC CHIP 560PF-J/50V
C233 00D 963 9005 778 C,ELECT 10UF-M/50V
C233X nsp 00D 960 9009 843 C,CERAMIC CHIP 1800PF-K/50V
C234X nsp 00D 963 9006 146 C,CERAMIC CHIP 560PF-J/50V
C235X 00D 963 9005 778 C,ELECT 10UF-M/50V
C236X nsp 00D 963 9006 146 C,CERAMIC CHIP 560PF-J/50V
C237X nsp 00D 960 9009 843 C,CERAMIC CHIP 1800PF-K/50V
C238X nsp 00D 963 9006 146 C,CERAMIC CHIP 560PF-J/50V
C239X 00D 963 9005 778 C,ELECT 10UF-M/50V
C240X 00D 960 9010 476 C,ELECT 22UF-M/50V
C241X 00D 960 9010 476 C,ELECT 22UF-M/50V
C242X 00D 963 9005 778 C,ELECT 10UF-M/50V
C243X 00D 963 9005 778 C,ELECT 10UF-M/50V
C244X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C245X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C246X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C247X nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C248X nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C249X nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C250X nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
OTHER PARTS GROUP
BD201 nsp 00D 963 0154 602 BEAD,COIL
BD201RM nsp 00D 963 0154 602 BEAD,COIL
BD201X nsp 00D 963 0234 603 COIL,BEAD
BD202 nsp 00D 963 0154 602 BEAD,COIL
Ref. No. nsp Part No. Part Name Remarks Q'ty New
