Denon AVR-2106 Service Manual

64
AVR-2106/886
BD202X nsp 00D 963 0234 603 COIL,BEAD
BD203 nsp 00D 963 0234 603 COIL,BEAD for AVR2106E3
BD204 nsp 00D 963 0234 603 COIL,BEAD for AVR2106E3
BD205 nsp 00D 963 0234 603 COIL,BEAD
BD206 nsp 00D 963 0220 002 BEAD,COIL 121JT for AVR2106E3
BD207 nsp 00D 963 0220 002 BEAD,COIL 121JT for AVR2106E3
BD208 nsp 00D 963 0220 002 BEAD,COIL 121JT for AVR2106E3
BD209 nsp 00D 963 0220 002 BEAD,COIL 121JT for AVR2106E3
CN201 nsp 00D 963 0086 107 CN.WAFER 16P
CN201X nsp 00D 963 0255 909 CN,WIRE 120MM/4P *
CN202 nsp 00D 963 0097 303 CN.WAFER 15P
CN204 nsp 00D 963 0256 209 CN,WIRE 70MM/7P *
CN204X nsp 00D 963 0097 206 CN.WAFER 8P
CN205X nsp 00D 963 0256 102 CN,WIRE 70MM/6P *
CP202X nsp 00D 963 0060 709 CN.WAFER 8P
CP203 00D 963 0149 303 CN.FPC 15P
CP203X nsp 00D 963 0068 303 CN.WAFER 9P
JACK203 00D 963 0256 500 CN.9P D-SUB for AVR2106E3 *
L201X nsp 00D 963 0145 103 COIL,INDUCTOR 22UH
L202X nsp 00D 963 0145 103 COIL,INDUCTOR 22UH
X202X 00D 262 3516 908 FCXO-03L(45.1584MHZ)
00D 963 0244 703 EARPHONE JACK, D3.5
00D 963 0146 209 TER,RCA 4PIN
00D 960 0268 803 TER,RCA 6PIN
- CUSHION (24*18*4.5t)
nsp 00D 963 0094 102 PLATE
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
