Denon AVR-2106 Service Manual

69
AVR-2106/886
2ch AMP P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC102X 00D 263 1092 003 IC BA05T
IC103X 00D 263 1223 005 IC PQ20RX11J00H
Q101SBL 00D 963 0235 301 TR 2SD2560Y
Q101SBR 00D 963 0235 301 TR 2SD2560Y
Q101X 00D 960 0097 304 TR KRC102M
Q102SBL 00D 963 0235 204 TR 2SB1647Y
Q102SBR 00D 963 0235 204 TR 2SB1647Y
Q102X 00D 960 0097 304 TR KRC102M
Q103SBL 00D 963 0058 106 TR 2SD947F
Q103SBR 00D 963 0058 106 TR 2SD947F
Q104SBL 00D 960 0196 506 TR KSC1845F
Q104SBR 00D 960 0196 506 TR KSC1845F
D102X 00D 963 0058 407 D, 1N4007
D102X1 00D 963 0058 407 D, 1N4007
D106 00D 963 0020 309 D, 1SS133
D107 00D 963 0020 309 D, 1SS133
RESISTORS GROUP
R104SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K
R104SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K
R105SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K
R105SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K
R106SBL 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R106SBR 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R107SBL 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R107SBR 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R108SBL 00D 963 9006 269 R,FIXED 1WJ-0.22
R108SBR 00D 963 9006 269 R,FIXED 1WJ-0.22
R109SBL 00D 963 9006 269 R,FIXED 1WJ-0.22
R109SBR 00D 963 9006 269 R,FIXED 1WJ-0.22
R110SBL 00D 963 9006 269 R,FIXED 1WJ-0.22
R110SBR 00D 963 9006 269 R,FIXED 1WJ-0.22
R111SBL 00D 963 9006 269 R,FIXED 1WJ-0.22
R111SBR 00D 963 9006 269 R,FIXED 1WJ-0.22
R118SBL 00D 963 9006 256 R,FIXED 1WJ-10
R118SBR 00D 963 9006 256 R,FIXED 1WJ-10
R119SBL 00D 963 9006 256 R,FIXED 1WJ-10
R119SBR 00D 963 9006 256 R,FIXED 1WJ-10
VR106 00D 963 0105 208 VR,SEMI 1KB
VR107 00D 963 0105 208 VR,SEMI 1KB
CAPACITORS GROUP
C101SBL 00D 963 0234 506 C,ELECT 47UF-M/50V
C101SBR 00D 963 0234 506 C,ELECT 47UF-M/50V
C101X 00D 963 9003 097 C,FILM 0.1UF-K/250V
C102SBL 00D 963 0234 205 C,ELECT 10UF-M/50V
C102SBR 00D 963 0234 205 C,ELECT 10UF-M/50V
C103SBL 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C103SBR 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C103X 00D 963 0255 501 C,ELECT 18000UF-M/16V *
C104SBL 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C104SBR 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C104X 00D 963 9005 794 C,ELECT 100UF-M/16V
C105SBL 00D 960 9008 640 C,FILM 0.022UF-J/100V
C105SBR 00D 960 9008 640 C,FILM 0.022UF-J/100V
C105X 00D 963 9005 794 C,ELECT 100UF-M/16V
