Denon AVR-2106 Service Manual

70
AVR-2106/886
C106X nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C106X1 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C107SBL 00D 963 9003 097 C,FILM 0.1UF-K/250V
C107SBR 00D 963 9003 097 C,FILM 0.1UF-K/250V
C107X 00D 963 9005 794 C,ELECT 100UF-M/16V
C108X nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
OTHER PARTS GROUP
CN102X nsp 00D 963 0256 306 CN,WIRE 90MM/5P *
CN506T nsp 00D 963 0245 401 CN,WIRE 140MM/15P
CP101X nsp 00D 960 0123 207 CN.WAFER 3P
CP992 nsp 00D 960 0217 553 CN.WAFER 4P
! F101X 00D 963 0256 607 FUSE T2A/250V *
L101SBL nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101SBR nsp 00D 963 0049 005 COIL,INDUCTOR 0.5UH
TP106 nsp 00D 963 0207 203 CN.WAFER 3P
TP107 nsp 00D 963 0207 203 CN.WAFER 3P
nsp 00D 960 0005 804 HOLDER,FUSE CLIP for F101XA
nsp 00D 960 0005 804 HOLDER,FUSE CLIP for F101XB
Ref. No. nsp Part No. Part Name Remarks Q'ty New
