84
YES
YES
YES
YES
Check TV
(11) Is the TV HDCP-compatible?
(16) Is the set's input set to HDMI?
(13) Is the TV's input set to HDMI?
(14) Are the picture and sound output when a different TV is used?
Check set (AVR-1913/2113)
(12) Is the TV compatible with resolutions of 1080P?
Use an HDCP-compatible TV. PC TVs cannot
be used.
Check the set's input setting, referring to the
set's operating instructions.
Check the TV's input setting, referring to the
TV's operating instructions.
The TV is defective.
If the TV is not compatible with resolutions of
1080P, no picture will be output, even if the
BD/DVD player resolution is set to 1080P.
NO
NO
NO
NO
NO
YES
NO
YES
YES
YES
The set does not recognize the TV.
(17) Is TP [HPD-OUT] set to the "H"(3V-5V)?
With the TV connected,check the voltage of the IC on the side on
which the TV is connected.
Is communication waveform conrmed in TP[DDCCLK-OUT/
DDCDATA-OUT]?
Is D1603/D1604/D1605/D1606/D1607/D1608/D1609/D1610
terminated by the TMDS signal of 3.3V and is the signal output?
(18)
When using a
DENON BD/DVD
player, is the FL
display's "HDMI"
indicator lit?
If using a non-
DENON BD/DVD
player, proceed
to "NO".
The pattern and circuit from the HDMI
connector (N1602) to the U1601 are defective,
or HDMI output circuitry is defective (U1601
and surrounding circuitry).
The BD/DVD player does not recognize the connection with the
set.
(19)
Is HDMI connector (N1001/N1002/N1003/N1004/N1302 : TP[HPD-IN1
- 5]) set to "H"(3V-5V)?
With the BD/DVD player connected, Check voltage of the HDMI
connector (N1001/N1002/N1003/N1004/N1302 : TP[
+5V - IN 1 - 5
]) for
the input on the side on which the BD/DVD player is connected.
Is communication waveform conrmed in TP[DDCCLK / DDCDATA IN
1 - 5] around each HDMI connector ?
Is TMDS line of HDMI connector (
N1001/N1002/N1003/N1004/N1302
)
terminated by the TMDS signal of 3.3V and is the signal output?
The pattern and
circuit from the
HDMI connector
(N1001/N1002/
N1003/N1004/
N1302) to the IC
(U1001 or U1302)
are defective.
NO
NO NO
(15) Is any PIN of the HDMI connector bent or is dust adhering to the
connector?
Malfunction of the HDMI connector.
(If dust is adhering, remove the dust and
perform the troubleshooting again from (1).)
YES
NO
Is a contact part of HDMI connector normal? (Refer to 86 page (*1).)
The HDMI connector is defective.
Replace the new HDMI connector.
NO
YES
(20)
VIDEO CONVERT : Is the picture output when it is set to off?
(After item (23) : To be "VIDEO CONVERT:OFF" setting.)
YES
U1601(ADV8002 (AVR-1913) / ADV8003
(AVR-2113)) and surrounding circuitry are
defective.
To Next Page
