Check operation of each device.
(AMP source : BD / Video input of player : 480P / Connect the TV.)
Check operation of U1(ADV3002).
(21) Check power supply.
Are 5V or 3.3V supplied to U1001 (each power supply pin)?
Refer to [Detail C] of the substrate for test point.
(22) Check RESET.
Is RESET waveform conrmed in TP[3002RESET], when the power is turned
on?(If the waveform is not the reference waveform, proceed to NO.)
(24) Check output signal.
Is TMDS waveform conrmed in 25pin/26pin/28pin/29pin/31pin/32pin/34pin/35pin.
Is communication waveform of DDC_SCL/DDC_SDA conrmed in
67pin/68pin? (If the waveform is not the reference waveform, proceed to NO.)
(23) Check Control signal (I2C).
Is waveform conrmed in TP[HSCL/HSDA], when the power is turned on? (If
the waveform is not the reference waveform, proceed to NO.)
The power supply circuitry is defective.
The RESET circuitry or U1001 is defective.
The U1001 is defective.
The pattern is defective of the HSCL/HSDA
line.
NO
NO
NO
NO
The HDMI input circuitry is defective.
(U1001 or U1302 and surrounding circuitry)
Check operation of U1302 (ADV7850).
(25) Check power supply.
Are 1.8V supplied to L3616?
Are 3.3V supplied to Q3608 1pin?
The power supply circuitry is defective.
NO
YES
(27) Check RESET.
Is RESET waveform conrmed in TP[7850RESET], when power is turned on?
(If the waveform is not the reference waveform, proceed to NO.)
The RESET circuitry or U1302 is defective.
NO
YES
YES
(26) Check xtal oscillator.
Is oscillation of X1301(27.0 MHz) transmitted?
The X1301 or U1302 is defective.
NO
To Next Page
