DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to
"DISASSEMBLY
1. FRONT PANEL ASSY"
and
"EXPLODED VIEW"
PCB FRONT HDMI
(Ref. No. of EXPLODED VIEW : P1)
PCB USB
(Ref. No. of EXPLODED VIEW : P2)
PCB FRONT
(Ref. No. of EXPLODED VIEW : P3)
PCB FUNCTION
(Ref. No. of EXPLODED VIEW : P4)
PCB CNT
(Ref. No. of EXPLODED VIEW : P5)
PCB FRONT HDMI_GUIDE
(Ref. No. of EXPLODED VIEW : P6)
RADIATOR ASSY
Refer to
"DISASSEMBLY
10. RADIATOR ASSY"
and
"EXPLODED VIEW"
PCB GUIDE R
(Ref. No. of EXPLODED VIEW : P7)
7CH AMP PCB ASSY
(Ref. No. of EXPLODED VIEW : P8)
PCB TOP_GUIDE
(Ref. No. of EXPLODED VIEW : P9)
PCB GUIDE L
(Ref. No. of EXPLODED VIEW : P10)
POWER TRANS MAIN
Refer to
"DISASSEMBLY
4. POWER TRANS MAIN"
and
"EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 32)
TOP COVER
PCB HDMI
Refer to
"DISASSEMBLY
3. PCB HDMI"
and
"EXPLODED VIEW"
PCB HDMI
(Ref. No. of EXPLODED VIEW : P16)
PCB MX PORT/PCB RS232C
Refer to
"DISASSEMBLY
2. PCB MX PORT/PCB RS232C"
and
"EXPLODED VIEW"
PCB RS232C
(Ref. No. of EXPLODED VIEW : P15)
PCB RC5_MXPORT
(Ref. No. of EXPLODED VIEW : P17)
PCB VIDEO ASSY
Refer to
"DISASSEMBLY
6. PCB VIDEO ASSY"
and
"EXPLODED VIEW"
PCB VIDEO
(Ref. No. of EXPLODED VIEW : P22)
PCB AUDIO ASSY
Refer to
"DISASSEMBLY
7. PCB AUDIO ASSY"
and
"EXPLODED VIEW"
PCB AUDIO ASSY
(Ref. No. of EXPLODED VIEW : P13)
BACK CHASSIS
PCB SMPS
Refer to
"DISASSEMBLY
5. PCB SMPS"
and
"EXPLODED VIEW"
PCB SMPS
(Ref. No. of EXPLODED VIEW : P18)
PCB REG/REG_CNT ASSY
Refer to
"DISASSEMBLY
11. PCB VIDEO ASSY"
and
"EXPLODED VIEW"
PCB REG
(Ref. No. of EXPLODED VIEW : P11)
PCB REG_CNT
(Ref. No. of EXPLODED VIEW : P12)
PCB PREOUT ASSY
Refer to
"DISASSEMBLY
8. PCB PREOUT ASSY"
and
"EXPLODED VIEW"
PCB SIDE _CNT
(Ref. No. of EXPLODED VIEW : P14)
PCB FRONT CNT
(Ref. No. of EXPLODED VIEW : P20)
PCB PREOUT
(Ref. No. of EXPLODED VIEW : P21)
PCB SPK ASSY
Refer to
"DISASSEMBLY
9. PCB SPK ASSY"
and
"EXPLODED VIEW"
PCB SPK
(Ref. No. of EXPLODED VIEW : P19)

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
