Denon AVR-2313 User Manual

EXPLODED VIEW
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:
印の部分は安全を維持するために重要
な部品です。従って交換時は必ず指定の
部品を使用してください。
16
19
20 X5
G x4
37
J X3
J X3
K X3
C x4
C x3
C X2
C x2
C x2
C X3
21
22
28
23
22
21
25 X3
32
C X5
H X21
P7
C
C x5
P9
C
C
P10
30
P8
24
L X7
K
1
14
18
3
4
6
7
8
9
5
P1
11
D x6
C
C X2
2
A X29
(FRONT PCB&FUNCTION PCB
H/P PCB&USB PCB&FRONT HDMI PCB&SUB PANEL+FRONT PANEL)
12
13
15
10
27 X4
26 X4
29
31
C
I
I
C
I
C
33
34
C
C
P11
P12
P21
P14
P16
P17
P19
P18
P20
C
P15
36
35
P13
P2
P3
P4
P5
P6
P22
L X2
L X2
L
38
41
40
40
41
J X2
22
39
PCB
GUIDE CABLE
BACK
6
2 1
3
9
8
5
4
7
19 17
13
33
13
19 17
15
z
160

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
