Denon AVR-2313 User Manual

217
VPT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC4800 231310009508S IC PQ033DNA1ZPH J126033010010S
IC4801 235810046603S IC AVDM2000(NJW1327) J171132700010S
D4802 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
D5000-5002 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
Q5001 943214500030S TR 2SC INC2001AC1 J522020011210S
Q5002 943215500030S TR 2SA RT1P441C J520104411210S
Q5004 943214500030S TR 2SC INC2001AC1 J522020011210S
Q5005 943215500030S TR 2SA RT1P441C J520104411210S
Q5006 943216500050S TR 2SC RT1N441C J522104411210S
Q5008 943214500030S TR 2SC INC2001AC1 E2,E1C J522020011210S
Q5009,5010 943215500030S TR 2SA RT1P441C J520104411210S
Q5012 943214500030S TR 2SC INC2001AC1 E2,E1C J522020011210S
Q5013 943216500050S TR 2SC RT1N441C J522104411210S
Q5015 943214500030S TR 2SC INC2001AC1 E2,E1C J522020011210S
Q5017 943214500030S TR 2SC INC2001AC1 J522020011210S
Q5019 943214500030S TR 2SC INC2001AC1 E2,E1C J522020011210S
Q5021 943214500030S TR 2SC INC2001AC1 E2,E1C J522020011210S
Q5023 943214500030S TR 2SC INC2001AC1 E2,E1C J522020011210S
Q5025 943215500030S TR 2SA RT1P441C E2,E1C J520104411210S
Q5027 943214500030S TR 2SC INC2001AC1 E2,E1C J522020011210S
Q5030 943214500030S TR 2SC INC2001AC1 J522020011210S
ZD5000 00D9630295503 ZENER DIODE 0.2W 3.6V (UMD2 TYPE) K06603R64P400S
RESISTORS GROUP
R5025,5026 nsp 470-J,1/16W-1608 E2,E1C C20004716M160S
R5027 nsp 220-J,1/16W-1608 E2,E1C C20002216M160S
R5029 nsp CHIP RES. 10K-J 1/16W-1608REEL E2,E1C C20001036M160S
R5030 nsp 470K-J,1/16W-1608 E2,E1C C20004746M160S
R5031,5032 nsp 100K-J,1/16W-1608 E2,E1C C20001046M160S
R5034 nsp 470K-J,1/16W-1608 E2,E1C C20004746M160S
R5037 nsp CHIP RES. 10K-J 1/16W-1608REEL E2,E1C C20001036M160S
R5038,5039 nsp 100K-J,1/16W-1608 E2,E1C C20001046M160S
R5041,5042 nsp 470-J,1/16W-1608 E2,E1C C20004716M160S
R5044,5045 nsp 470-J,1/16W-1608 E2,E1C C20004716M160S
R5043 nsp 220-J,1/16W-1608 E2,E1C C20002216M160S
R5046 nsp 220-J,1/16W-1608 E2,E1C C20002216M160S
R5048 nsp CHIP RES. 10K-J 1/16W-1608REEL E2,E1C C20001036M160S
R5049 nsp 470K-J,1/16W-1608 E2,E1C C20004746M160S
R5050,5051 nsp 100K-J,1/16W-1608 E2,E1C C20001046M160S
R5060,5061 nsp 470-J,1/16W-1608 E2,E1C C20004716M160S
R5062 nsp 220-J,1/16W-1608 E2,E1C C20002216M160S
R5064 nsp CHIP RES. 10K-J 1/16W-1608REEL E2,E1C C20001036M160S
R5065 nsp 470K-J,1/16W-1608 E2,E1C C20004746M160S
R5066,5067 nsp 100K-J,1/16W-1608 E2,E1C C20001046M160S
R5068 nsp 470K-J,1/16W-1608 E2,E1C C20004746M160S
R5070 nsp CHIP RES. 10K-J 1/16W-1608REEL E2,E1C C20001036M160S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
