Denon AVR-2313 User Manual

218
Ref. No. Part No. Part Name Remarks Q'ty New
R5071,5072 nsp 100K-J,1/16W-1608 E2,E1C C20001046M160S
R5073,5074 nsp 470-J,1/16W-1608 E2,E1C C20004716M160S
R5075 nsp 220-J,1/16W-1608 E2,E1C C20002216M160S
R5076,5077 nsp 470-J,1/16W-1608 E2,E1C C20004716M160S
R5078 nsp 220-J,1/16W-1608 E2,E1C C20002216M160S
R5080 nsp CHIP RES. 10K-J 1/16W-1608REEL E2,E1C C20001036M160S
R5081,5082 nsp 100K-J,1/16W-1608 E2,E1C C20001046M160S
R5083 nsp 470K-J,1/16W-1608 E2,E1C C20004746M160S
R5084 nsp 1K-J,1/16W-1608 E2,E1C C20001026M160S
R5085,5086 nsp 470K-J,1/16W-1608 E2,E1C C20004746M160S
R5088 nsp CHIP RES. 10K-J 1/16W-1608REEL E2,E1C C20001036M160S
R5089,5090 nsp 100K-J,1/16W-1608 E2,E1C C20001046M160S
R5092,5093 nsp 470-J,1/16W-1608 E2,E1C C20004716M160S
R5094 nsp 220-J,1/16W-1608 E2,E1C C20002216M160S
CAPACITORS GROUP
C4800,4801 963134002740S C,ELECT 10UF-M/16V D040100083100S
C4802 nsp C,ELECT 47UF-M/16V D040470083080S
C4803 nsp C,CERAMIC 1UF-K/16V D011105173161S
C4806 nsp C,CERAMIC 1UF-K/16V D011105173161S
C4807-4809 963134002740S C,ELECT 10UF-M/16V D040100083100S
C4810-4815 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4816,4817 nsp C,ELECT 47UF-M/16V D040470083080S
C4818-4826 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4829,4830 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4831-4836 nsp C,CERAMIC 10UF-K/16V D011106573200S
C5000 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C5001,5002 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C5003 nsp C,CERAMIC 330PF-J/50V D010331167160S
C5005 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5006 nsp C,CERAMIC 330PF-J/50V D010331167160S
C5007 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C5008,5009 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C5011,5012 00D9630224503 C,ELECT 22UF-M/50V E2,E1C D040220087060S
C5013 nsp C,CERAMIC 330PF-J/50V E2,E1C D010331167160S
C5015 nsp C,CERAMIC 330PF-J/50V E2,E1C D010331167160S
C5016 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C5017-5020 00D9630224503 C,ELECT 22UF-M/50V E2,E1C D040220087060S
C5021 nsp C,CERAMIC 330PF-J/50V E2,E1C D010331167160S
C5023 nsp C,CERAMIC 330PF-J/50V D010331167160S
C5024,5025 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C5026,5027 00D9630224503 C,ELECT 22UF-M/50V E2,E1C D040220087060S
C5029 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5030 nsp C,CERAMIC 330PF-J/50V E2,E1C D010331167160S
C5031-5034 00D9630224503 C,ELECT 22UF-M/50V E2,E1C D040220087060S
C5035 nsp C,CERAMIC 330PF-J/50V E2,E1C D010331167160S
C5036 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5037 nsp C,CERAMIC 330PF-J/50V E2,E1C D010331167160S
C5038 nsp C,CERAMIC 0.1UF-K/50V E2,E1C D011104577160S
C5039,5040 00D9630224503 C,ELECT 22UF-M/50V E2,E1C D040220087060S
C5041,5042 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C5043 nsp C,CERAMIC 330PF-J/50V D010331167160S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
