Denon AVR-2313 User Manual

219
Ref. No. Part No. Part Name Remarks Q'ty New
C5044 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5045 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C5046 nsp C,CERAMIC 100PF-J/50V D010101167160S
C5047 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5048 nsp C,CERAMIC 100PF-J/50V D010101167160S
C5049 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C5054-5058 nsp C,CERAMIC 100PF-J/50V D010101167160S
C5059 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
OTHERS PARTS GROUP
CN4002 nsp
CN,WIRE 2MM,I950MM/13P
20010HS-13=CKM2002HV-13 WH1007#26 TAPE
L002500130040S
CN4603 nsp
CN,WAFER,I9C125Z2-11 11P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521120S
CN4604 nsp
CN,WAFER,I9C125Z2-17 17P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521720S
CN4608 nsp
CN,WAFER,I9C125Z2-09 9P BtoB
SOCKET(FEMALE) P=1.25MM
L109012520920S
CN4613 nsp
CN,WAFER,I9C125Z2-13 13P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521320S
CN4614 nsp
CN,WAFER,I9C125Z2-07 7P BtoB
SOCKET(FEMALE) P=1.25MM
L109012520720S
CP4800 nsp CN.WAFER 4P 20010WR-04 L101200100420S
CP5003 943183100200S
TUNER,FM,I9KST-MW004FV1-S63SV
4GANG+FM ONLY+50US
E900004010030S
CP5003 943183100210S TUNER,FM,I9KST-MW104FV1-S63V E2 E900104011630S
CP5003 943183100220S TUNER,FM,I9KST-MW004FV1-S63 E1C E900004010630S
CP5005 nsp
CN,WAFER,I9C125Z1-19 19P BtoB
HEADER(MALE) P=1.25MM
L109012511920S
JK4800 963643005090S TERMINAL RCA 1PIN G600107AY000YS
JK4801 963643003460S TER,RCA 4PIN G602405BE310YS
JK4802-4804 963643101630D TER,RCA 3PIN RCA-303B1-08 G606303B1080YS
JK5000_4 00D9630132103 TER,RCA 4PIN RCA-405B-04 G602405B0400YS
JK5000_6 963646007620M RCA-603B-05 NI(WWW,RRR)GND=0 E2,E1C G603603B0500YS
JK5001_1 00D9630146005 TER,RCA 1PIN G600107A0000YS
JK5001_6 963643101820S RCA-603B-96(WHWHWH,BKRDRD) E2,E1C G603603B9600YS *
JK5002 00D9630146005 TER,RCA 1PIN G600107A0000YS
L5000 nsp COIL,BEAD CBW160808U121T D340160811210S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
