Denon AVR-2313 User Manual

201
Ref. No. Part No. Part Name Remarks Q'ty New
R487 nsp R,METAL FILM 270-J,1W C060027165060S
R491,492 nsp R,METAL FILM 270-J,1W C060027165060S
R494 963252100150S
POSISTOR,I9DHPTHF1608 471P
115T SMD PTC THERMISTOR
F320471001150S
R497 nsp JUMPER (0.6/52MM) L045084006040S
R502 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R505 963125010690S R,METAL FILM 15K-J,2W C060015366050S
R511,512 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R515 nsp JUMPER (0.6/52MM) L045084006040S
R517,518 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R521 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R526 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R528,529 nsp R,METAL FILM 1K-J,1W C060010265050S
R530 nsp R,METAL FILM 270-J,1W C060027165060S
R533 nsp R,METAL FILM 270-J,1W C060027165060S
R535 nsp R,METAL FILM 270-J,1W C060027165060S
R537 963252100150S
POSISTOR,I9DHPTHF1608 471P
115T SMD PTC THERMISTOR
F320471001150S
R540 nsp JUMPER (0.6/52MM) L045084006040S
R545 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R550 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R550 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R554,555 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R558 nsp JUMPER (0.6/52MM) L045084006040S
R561,562 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R563 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R563 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R564 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R569 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R571,572 nsp R,METAL FILM 1K-J,1W C060010265050S
R573 nsp R,METAL FILM 270-J,1W C060027165060S
R576 nsp R,METAL FILM 270-J,1W C060027165060S
R578 nsp R,METAL FILM 270-J,1W C060027165060S
R580 963252100150S
POSISTOR,I9DHPTHF1608 471P
115T SMD PTC THERMISTOR
F320471001150S
R583 nsp JUMPER (0.6/52MM) L045084006040S
R588 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R591 963125010690S R,METAL FILM 15K-J,2W C060015366050S
R593 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R593 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R597,598 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R601 nsp JUMPER (0.6/52MM) L045084006040S
R603,604 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R606 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R606 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R607 nsp R,METAL FILM 3.3K-J,1W C060033265050S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
