Denon AVR-2313 User Manual

204
Ref. No. Part No. Part Name Remarks Q'ty New
C463,464 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C466 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C469 nsp C,CERAMIC 220PF-J/50V D010221167160S
C470 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C471 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) E3 D040470087070S
C471 963134501660S C,ELECT GE 85C 220UF-M/25V E2,E1C D040221084060S
C472 00D9630224503 C,ELECT 22UF-M/50V E3 D040220087060S
C472 963134501910S C,ELECT GE 85C 47UF-M/50V E2,E1C D040470087140S
C473 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C474 00D2544574922 C,ELECT 100UF-M/50V E3 D040101087060S
C474 963134001860S C,ELECT 470UF-M/16V E2,E1C D040471083080S
C475,476 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C477 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C479,480 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C482 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C485 nsp C,CERAMIC 220PF-J/50V D010221167160S
C486 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C487 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) E3 D040470087070S
C487 963134501660S C,ELECT GE 85C 220UF-M/25V E2,E1C D040221084060S
C488 00D9630224503 C,ELECT 22UF-M/50V E3 D040220087060S
C488 963134501910S C,ELECT GE 85C 47UF-M/50V E2,E1C D040470087140S
C489 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C490 00D2544574922 C,ELECT 100UF-M/50V E3 D040101087060S
C490 963134001860S C,ELECT 470UF-M/16V E2,E1C D040471083080S
C491,492 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C493 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C495,496 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C498 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C501 nsp C,CERAMIC 220PF-J/50V D010221167160S
C502 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C503 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) E3 D040470087070S
C503 963134501660S C,ELECT GE 85C 220UF-M/25V E2,E1C D040221084060S
C504 00D9630224503 C,ELECT 22UF-M/50V E3 D040220087060S
C504 963134501910S C,ELECT GE 85C 47UF-M/50V E2,E1C D040470087140S
C505 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C506 00D2544574922 C,ELECT 100UF-M/50V E3 D040101087060S
C506 963134001860S C,ELECT 470UF-M/16V E2,E1C D040471083080S
C507,508 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C509 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C511,512 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C513,514 00D9630338402 C,ELECT 330UF-M/6.3V D040331081050S
C515 00D2544538913 C,ELECT 22UF-M/16V D040220083070S
OTHERS PARTS GROUP
BKT400 nsp BRACKET 0.8t/SCREW 4010210196100S
CN404 nsp CN,WIRE 2MM,I9CN,WIRE 2MM L002241050090S
CP401 nsp CN.WAFER 13P STRAIGHT L101200101310S
CP402 nsp CN.WAFER 5P 5267-05A L102526700500S
CP403 nsp CN.WAFER 10P STRAIGHT L101200101010S
CP405 nsp CN.WAFER 3P 5267-03A L102526700300S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
